Canadian Solar EP CUBE 7.6kW Hybrid Inverter + 13.3 kwh Batteries all-in-one system.
Product form
Regular price
£4,689.00
Regular price
Sale price
£4,689.00
Unit price
/
£5,626.80 INC. VAT
In stock
Fast shipping
Collection available More info
Overview
Click Here To Register For The On-line Installation Training Course
10 Year warranty as standard
INCLUDED IN PACKAGE:
7.6KW HYBRID INVERTER
3.3 KWH BATTERIES X 4
TOP COVER
FLOOR BASE
WIFI DONGLE
SMART METER
INTERNAL DC BREAKER
HYBRID INVERTER 7.6KW
- Max DC input 10kwp
- 7600W nominal AC output power
- IP67 rating
- Dimensions (W x H x D)mm 600 x 1435 x 243
- 10 year warranty
BATTERIES
- 13.3kW OF POWER FROM THE 4 x BATTERIES COMBINED
- DOC 100%
- VOLTAGE RANGE 30v - 43.8v
- WEIGHT OF EACH BATTERY: 35kg
- IP RATING: IP67
INTEGRATED PROTECTION
Battery Input Reverse / Polarity Protection
Over load Protection (DC-AC side)
AC Short Circuit Current Protection / Output Short Protection
Output Over Current Protection
DC (PV+Battery) Short Circuit Current Protection
AC Surge Protection (SPD -Type) Output Over Voltage Protection
Grid and Back-up (SPD Type II)
Anti Islanding Protection
PV String Input Reverse Polarity Protection
Ground Fault Monitoring
Temperature Protection (Inverter + Battery)
Integrated DC Switch (PV - Disconnector)
Emergency Stop
