Solis

Part No: SOL-S5-GC25K-DC Inverters - Main Units Rating: 25,000W Phases: 3 S5-GC25K - Series 5 Three Phase Grid-Tied Inverter Product Features: Max. efficiency of 98.5%  Type-II over-voltage surge protection for both DC and AC Wide voltage range - Ultra low start-up voltage of 180V and max PV input voltage of 1100V 32A input per MPPT, 16A input for each PV string Maximum AC output power of 27.5kW  3 MPPT design with precise MPPT algorithm, with 2 DC inputs per MPPT effectively reducing string mismatch Intelligent monitoring, Smart I-V Curve Diagnosis Integrated AFCI (DC arc-fault circuit protection) IP66 Rated  DC reverse-polarity protection 5-year standard warranty Register on SolisCloud, to support remote upgrade and control. SA: NRS-097-2-1 Certified EU: German installation manual stlll pending from manufacturer. UK: Please note that a slight adjustment was required on the G99 report which has resulted in S5-GC range temporarily losing their G99 approved status. The updated form has already been resubmitted to the ENA and is currently awaiting assessment. This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. SegenSolar will not be held liable for any product malfunctions as a  result of incorrectly installed systems. Supplier Part No: SOL-S5-GC25K-DCWeight: 66 kgRated Power: 25,000 WMin PPT Voltage: 200 VMax PPT Voltage: 1,000 VDC Startup Voltage: 200 VDC Shutdown Voltage: 180 VMax Input Voltage: 1,100 VMax DC Power:  37,500 WMax AC Power (5 Minutes): 25,000 WSurge AC Power (1 Second): 27,500 WMax DC Current: 96 AMax DC Inputs: 6Has DC Fuses: 0Connector: MC4Included Connectors: 12Euro Efficiency: 98.1 %Transformer: NoneMPPT Quantity : 3Has Integrated DC Switch: YesWarranty: 5 years Click Here For Specs

Read more less

Part No: SOL-S5-GC40K-DC Inverters - Main Units Rating: 40,000W Phases: 3 S5-GC40K - Series 5 Three Phase Grid-Tied Inverter Product Features: Max. efficiency of 98.7%  Type-II over-voltage surge protection for both DC and AC Wide voltage range - Ultra low start-up voltage of 180V and max PV input voltage of 1100V 32A input per MPPT, 16A input for each PV string Maximum AC output power of 44kW  4 MPPT design with precise MPPT algorithm, with 2 DC inputs per MPPT effectively reducing string mismatch Intelligent monitoring, Smart I-V Curve Diagnosis Integrated AFCI (DC arc-fault circuit protection) IP66 Rated  DC reverse-polarity protection 5-year standard warranty Register on SolisCloud, to support remote upgrade and control. SA: NRS-097-2-1 Certified. UK: G99 Certified. This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. SegenSolar will not be held liable for any product malfunctions as a  result of incorrectly installed systems. Supplier Part No: SOL-S5-GC40K-DCWeight: 52 kgRated Power: 40,000 WMin PPT Voltage: 200 VMax PPT Voltage: 1,000 VDC Startup Voltage: 200 VDC Shutdown Voltage: 180 VMax Input Voltage: 1,100 VMax DC Power: 60,000 WMax AC Power (5 Minutes): 44,000 WSurge AC Power (1 Second): 44,000 WMax DC Current: 128 AMax DC Inputs: 8Has DC Fuses: 0Connector: MC4Included Connectors: 16Euro Efficiency: 98.3 %Transformer: NoneMPPT Quantity : 4Has Integrated DC Switch: YesWarranty: 5 years Click Here For Specs

Read more less

Part No: SOL-0.7-MINI-5G Inverters - Main Units Rating: 700W Phases: 1 All new Solis Mini 5G Series Grid-tie Inverter  Ultra low Startup Voltage  - 60V   High switch frequency technology-Smaller, smarter   DRM integrated fully comply with AS47772:2015   Compact and lightweight visually pleasing for domestic environment   5 years standard warranty 20 years optional upgrade   Export Limitation built in - Requires CT clamp (sold separately)   Integrated AFCI (DC arc-fault circuit protection) Supplier Part No: S5-GR1P0.7K-M Weight: 8.5 kg Rated Power: 700 W Min PPT Voltage: 50 V Max PPT Voltage: 500 V DC Startup Voltage: 60 V DC Shutdown Voltage: 50 V Max Input Voltage: 600 V Max DC Power: 900 W Max AC Power (5 Minutes): 800 W Surge AC Power (1 Second): 800 W Max DC Current: 12.5 A Max DC Inputs: 1 Has DC Fuses: 0 Connector: MC4   Included Connectors: 1 Euro Efficiency: 96.5 % Transformer: None IP Rating: IP65MPPT Quantity : 1 Has Integrated DC Switch: No Warranty: 5 years

Read more less

Part No: SOL-2.0-MINI-5G Inverters - Main Units Rating: 2,000W Phases: 1 All new Solis Mini 5G Series Grid-tie Inverter  Ultra low Startup Voltage  - 90V   High switch frequency technology-Smaller, smarter   DRM integrated fully comply with AS47772:2015   5 years standard warranty 20 years optional upgrade   Export Limitation built in - Requires CT clamp (sold separately)   Integrated AFCI (DC arc-fault circuit protection) Supplier Part No: S5-GR1P2K-M Weight: 8.1 kg Rated Power: 2,000 W Min PPT Voltage: 80 V Max PPT Voltage: 500 V DC Startup Voltage: 90 V DC Shutdown Voltage: 80 V Max Input Voltage: 600 V Max DC Power: 2,300 W Max AC Power (5 Minutes): 2,200 W Surge AC Power (1 Second): 2,200 W Max DC Current: 12.5 A Max DC Inputs: 1 Has DC Fuses: 0 Connector: MC4   Included Connectors: 1 Euro Efficiency: 96.5 % Transformer: None IP Rating: IP65MPPT Quantity : 1 Has Integrated DC Switch: No Warranty: 5 years

Read more less

Part No: GROWATT-MIC3000-TL-X-DC Inverters - Main Units Rating: 3,000W Phases: 1 Growatt inverters are designed specifically for residential rooftop applications. With a maximum efficiency of 97% and a wide input voltage range, this robust inverter is perfect for residential installations. The TL-X range has a single MPPT.  The Growatt inverter range has the following leading-edge technology. MPPT tracking accuracy of 99% Max. Efficiency 97.6%, European Efficiency 96.5% Transformerless design, offer lighter and more convenient installation  Power factor continuously adjustable Flexible interface Touch key & OLED display This is the Non-DC version.   Supplier Part No: MIC3000 TL X DC Weight: 6 kg Rated Power: 3,000 W Min PPT Voltage: 80 V Max PPT Voltage: 550 V DC Startup Voltage: 80 V DC Shutdown Voltage: 65 V Max Input Voltage: 550 V Max DC Power: 3,500 W Max AC Power (5 Minutes): 3,000 W Surge AC Power (1 Second): 0 W Max DC Current: 13 A Max DC Inputs: 1 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 0 Euro Efficiency: 97.1 % Transformer: None MPPT Quantity : 1 Has Integrated DC Switch: Yes Warranty: 10 years

Read more less

Part No: SOL-6.0-5G-DT-DC Inverters - Main Units Rating: 6,000W Phases: 1 Solis 5G is the 5th generation of inverters from Solis. This range of inverters are leaders in affordable small residential and commercial rooftop installations.  Product Features   Multi-working mode fully compatible with new AS4777.2:2015 standard   Easy installation: Integrate with export power control function and DRM function.   Max. Efficiency over 97.8% European efficiency over 97.1%   Ultra wide input voltage range   Dual MPPT design with precise MPPT algorithm   Maximum string input current 12.5A   Export Limitation built in - Requires CT clamp (sold separately)   Integrated AFCI (DC arc-fault circuit protection) With built in DC switch.    Supplier Part No: S5-GR1P6K-DC Weight: 11.5 kg Rated Power: 6,000 W Min PPT Voltage: 120 V Max PPT Voltage: 520 V DC Startup Voltage: 120 V DC Shutdown Voltage: 90 V Max Input Voltage: 600 V Max DC Power: 6,600 W Max AC Power (5 Minutes): 6,000 W Surge AC Power (1 Second): 6,000 W Max DC Current: 25 A Max DC Inputs: 2 Has DC Fuses: 0 Connector: MC4   Included Connectors: 2 Euro Efficiency: 97.3 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less
