Part No: SUN2000-LUNA-5KWh Storage Systems - Li-ion Battery Pack This part is made up of the following items: Huawei LUNA 5KWh battery module only Huawei LUNA Power Module BMS Smart String Energy. This is the complete 5KWh Luna Battery. Product Features Flexible due to 5KWh that can be easy scaled from 5KWh to 30KWh 100% DOD pack level energy optimization Easy to install due to 12Kg power module and 50Kg battery module Lithium Iron Phosphate cells resulting is safe and reliable battery Auto Detected by battery Compatible with single and 3 Phase inverters Battery fault on module auto isolates to keep system safe battery module is 5 KWh per module  this consists of 1 x battery module and 1 x power module Nominal voltage of battery is 600VDC max output per module is 2500W 10 year warranty max is 2 x systems in parallel RS485 BMS communication  IP66 Weight: 71 kg Battery Type: Lithium Ion Nominal Energy: 5000 Wh Depth of discharge: 100.00 % Voltage: 600 V Continuous Discharge Rate (Normal Use): 2500 W Maximum Discharge Rate (5 Minutes): 2500 W Surge Discharge Rate (15 Seconds): 2500 W Maximum Charge Rate (5 Minutes): 2500 W Data Sheet Huawei Luna

Read more less

Huawei 1ph 6kW / Luna 15KWh PackagePart No: SUN5KTL-L1-LUNA-15 Storage Systems – Self Consumption Packages This part is made up of the following items: 3 x SUN2000-LUNA-5KW-EO Huawei LUNA 5KWh battery module only 1 x SUN6KTL-L1 Huawei 6kW HV hybrid storage inverter L1 1 x SUN2000-LUNA-5KW-CO Huawei LUNA power module   The Smart Energy Controller (SUN2000-3/ 3.68/ 5-L1) is Huawei new single-Phase inverter and is direct compatible with their own Huawei Luna battery Product Features Direct compatible with Luna battery and is Plug and Play and no extra devices is needed AI Self leaning new arc detection Is compatible with the Sun2000-450W-P optimizer Simple commissioning by APP Auto-detection of system equipment Registering your plant by scanning any device Energy Flow illustration Real-time data at anytime and anywhere Performance data back-up Physical & logical module layout Module -level performance monitoring Smart I-V Diagnosis Smart dongle Plug and Play (LAN or 4G dongle available) Smart Dongle support up to 10 inverters IP65 Smart String Energy By Luna Flexible due to 5KWh that can be easy scaled from 5KWh to 30KWh 100% DOD pack level energy optimization Easy to install due to 12Kg power module and 50Kg battery module More usable energy with pack level energy optimization Lithium Iron Phosphate cells resulting is safe and reliable battery Auto Detected by battery Compatible with single and 3 Phase inverters Battery fault on module auto isolates to keep system safe IP66

Read more less

Part No: SUN2000-LUNA-5KW-CO Storage Systems - Battery Base This is the power mudule that goes with the Luna battery modules Product Features Easy to install due to 12Kg power module   Supplier Part No: 01074646 Weight: 16 kg Data Sheet Huawei Luna

Read more less

2 x  Huawei LUNA 5KWh battery module only   1 x  Huawei LUNA Power Module BMS   Smart String Energy By Luna  This is the complete 10KWh Luna Battery Product Features Flexible due to 5KWh that can be easy scaled from 5KWh to 30KWh 100% DOD pack level energy optimization Easy to install due to 12Kg power module and 50Kg battery module Lithium Iron Phosphate cells resulting is safe and reliable battery Auto Detected by battery Compatible with single and 3 Phase inverters Battery fault on module auto isolates to keep system safe battery module is 10 KWh per battery  this consists of 2 x battery modules and 1 x power module Nominal voltage of battery is 600VDC max output per module is 2500W 10 year warranty max is 2 x systems in parallel RS485 BMS communication  IP66 Data Sheet Huawei Luna

Read more less

Part No: HUAWEI-PWR-MGMT-250A-UK Power Management - Export Limitation 3ph This part is made up of the following items: 1 x HUA-SL_3000A Huawei Smart Logger 3000A   1 x DTSU666-H-3PH-250A Huawei DTSU666-H Three Phase Energy Meter with 3x 250A CT   Huawei Export Control Solution measures the active power at the point of connection to the distribution system, and then uses the information to control the inverters output power and balance the customer demand in order to control the export power to the distribution system for not exceeding agreed export capacity.  This system complies with UK G100 regulations with regards to reaction times and fail-safe functionality. This package is required for multiple Huawei inverters per site. Single inverter systems can limit export using DTSU666-H-3PH-250A meter only. Please note current clamps should be sized according to incoming grid supply in the property (not size of the PV array), please check if these 250A CTs are sufficient before buying.  Weight: 4.8 kg

Read more less

Part No: HUA-SMART-DONGLE-4G Display - Web Interfaces Huawei Smart Dongle - 4G Mobile Network adapter SDongleA-03 (HUA-SMART-DONGLE-4G) is a smart communications expansion module that works with Huawei inverters: (SUN2000-3/4/5/6/8/10KTL-M0 Sun2000-12/15/17/20KTL-M0 SUN2000-60KTL-M0 SUN2000-100KTL-M1) to implement wireless communication between inverters and the management system through the 4G network.   A Smart Dongle can be used for daisy chaining devices using RS485 communication (inverter daisy chained, or inverters connected with other devices). A maximum of 10 devices can be connected together. When multiple inverters are connected together, only one Smart Dongle or one SmartLogger is allowed.   Supplier Part No: 02312EHS Weight: 0.09 kg

Read more less

Part No: HUA-SMART-WLAN-FE  Display - Web Interfaces   Huawei Smart Dongle  - Wi-Fi and Ethernet SDongleA-05 (HUA-SMART-WLAN-FE) is a smart communications expansion module that works with  Huawei inverters (3KTL-M0 to 20KTL-M0) to implement communication between inverters and the management system using WLAN (Wireless) or FE (Fast Ethernet). A Smart Dongle can be used for daisy chaining devices using RS485 communication (inverter daisy chained, or inverters connected with other devices). A maximum of 10 devices can be connected together. When multiple inverters are connected together, only one Smart Dongle or one SmartLogger is allowed.

Read more less

Part No: HUA-SL-3000A Display - Dataloggers The Huawei Smart Logger 3000A is dedicated to monitoring and managing a PV power generating system. It converges all ports, converts protocols, collects and stores data, and centrally monitors and maintains. SMART IEC60870-5-104 for connections to third-party monitoring systems; USB and embedded web for data reading and software upgrade; Automatically detecting equipment and assigning RS485 addresses; Remote control of active & reactive power SIMPLE Up to 80 inverters feeding into one Smart Logger; Up to 30 devices per RS485 bus; Easy to install on walls, tabletops and rails mounting RELIABLE Max. reliable communication range of 1000m; Remote configuration, automatic set-up of RS485 addresses Now with built in SPD Compatible with older Huawei -V1 inverter range and newer -M0, -H1 inverter range. 3G/4G router built in - NOT IN UNITS OFFERED IN SOUTH AFRICA . Please refer to the documents tab for associated G100 certificates.   Supplier Part No:SMARTLOGGER-3000A Weight:3.3 kg

Read more less

Part No: SUN2000-100KTL-M1 Inverters - Main Units Rating: 100,000W Phases: 3 Huawei SUN2000-100KTL-M1 Smart String Inverter Product Features   Smart   20 strings with 10x MPPT intelligent monitoring and fast trouble-shooting Smart I-V Curve Diagnosis supported Safe   DC disconnect integrated, safe and convenient for maintenance Residual Current Detection (RCD) protection Fuse free design Reliable   Protection rating of IP66 Type II surge arresters for both DC and AC Please note this inverter can be set to standard 400V or medium voltage 480V AC grid depending on Grid Code chosen on commissioning. Please see the manual for details.   This inverter has no screen and must be commissioned either by using the SUN2000 app on an Android phone and IOS or by connecting the unit to the Smart Logger.   Supplier Part No: 01074695-001 Weight: 90 kg Rated Power: 100,000 W Min PPT Voltage: 200 V Max PPT Voltage: 1,000 V DC Startup Voltage: 200 V DC Shutdown Voltage :200 V Max Input Voltage: 1,000 V Max DC Power: 135,000 W Max AC Power (5 Minutes): 100,000 W Surge AC Power (1 Second): 100,000 W Max DC Current: 260 A Max DC Inputs: 20 Has DC Fuses: 0 Connector: MC4   Included Connectors: 40 Euro Efficiency: 98.8 % Transformer: None MPPT Quantity : 10 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-100KTL-M1-AFCI Inverters - Main Units Rating: 100,000W Phases: 3 Huawei SUN2000-100KTL-M1-AFCI Smart String Inverter Product Features   Smart   20 strings with 10x MPPT intelligent monitoring and fast trouble-shooting Smart I-V Curve Diagnosis supported Safe   DC disconnect integrated, safe and convenient for maintenance Residual Current Detection (RCD) protection Fuse free design Reliable   Protection rating of IP66 Type II surge arresters for both DC and AC Please note this inverter can be set to standard 400V or medium voltage 480V AC grid depending on Grid Code chosen on commissioning. Please see the manual for details.   This inverter has no screen and must be commissioned either by using the SUN2000 app on an Android phone and IOS or by connecting the unit to the Smart Logger.   UK ONLY: Export Limitation possible with additional Power Management packages. Not certified for Republic of Ireland. Supplier Part No: 01074695-013 Weight: 90 kg Rated Power: 100,000 W Min PPT Voltage: 200 V Max PPT Voltage: 1,000 V DC Startup Voltage: 200 V DC Shutdown Voltage: 200 V Max Input Voltage: 1,000 V Max DC Power: 135,000 W Max AC Power (5 Minutes): 100,000 W Surge AC Power (1 Second): 100,000 W Max DC Current: 260 A Max DC Inputs: 20 Has DC Fuses: 0 Connector: MC4   Included Connectors: 40 Euro Efficiency: 98.8 % Transformer: None MPPT Quantity : 10 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-10KTL-M1 Storage Systems - Hybrid Inverter The Smart Energy Center of Huawei is the perfect solution where three phase power is needed with the added benefit of having a HV battery connected as well.  Product Features Wide range on PV input  2 x MPPT inputs Single inverter with Three Phase output High voltage battery input Type II AC and DC surge protection  Arc Fault detection8 Anti-islanding protection Integrated PID recovery Compatible with Huawei Smart ESS battery 5KWh to 30KWh IP65   2019 Inter Solar Award Winner   Supplier Part No: 01074311-001 Weight: 17 kg Rated Power: 10,000 W Min PPT Voltage: 140 V Max PPT Voltage: 980 V DC Startup Voltage: 200 V DC Shutdown Voltage: 140 V Max Input Voltage: 1,100 V Max DC Power: 15,000 W Max AC Power (5 Minutes): 11,000 W Surge AC Power (1 Second): 11,001 W Max DC Current: 22 A Max DC Inputs: 2 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 2 Euro Efficiency: 98.1 % Transformer: HF MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 10 years

Read more less

Part No: SUN2000-12KTL-M2 Inverters - Main Units Rating: 12,000W Phases: 3 The Huawei SUN2000-12KTL-M2 12kW 3phase inverter has a maximum efficiency up to 98.6 with an adaptable and flexible triple MPPT. DC & AC lightning protection is integrated into the unit and the natural cooling effectively improves product reliability. Smart Maximum of 2 MPPT for versatile adaption to different module types or quantities built up with different alignments Up to 4 strings intelligent monitoring and fault detection Exceptionally wide MPPT range. RS 485 and USB ports for connectivity and data management Local graphic LCD and optional remote monitoring via the NetEco portal or app. Efficient Maximum efficiency 98.5% European efficiency 98% <1W consumption during the night Safe DC and AC surge protection devices integrated Noise ≤ 29dB, Class-B electromagnetic radiation RCD protection function Reliable Product warranty of 10 years Natural cooling technology with heat sink Outdoor application of IP65   Supplier Part No: 01074319-005 Weight: 25 kg Rated Power: 12,000 W Min PPT Voltage: 140 V Max PPT Voltage: 950 V DC Startup Voltage: 200 V DC Shutdown Voltage: 140 V Max Input Voltage: 1,080 V Max DC Power: 18,000 W Max AC Power (5 Minutes): 12,000 W Surge AC Power (1 Second): 13,200 W Max DC Current: 44 A Max DC Inputs: 4 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 4 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-15KTL-M2 Inverters - Main Units Rating: 15,000W Phases: 3 The Huawei SUN2000-15KTL-M2 15kW 3phase inverter has a maximum efficiency up to 98.6 with an adaptable and flexible triple MPPT. DC & AC lightning protection is integrated into the unit and the natural cooling effectively improves product reliability. Smart Maximum of 2 MPPT for versatile adaption to different module types or quantities built up with different alignments Up to 4 strings intelligent monitoring and fault detection Exceptionally wide MPPT range. RS 485 and USB ports for connectivity and data management Local graphic LCD and optional remote monitoring via the NetEco portal or app. Efficient Maximum efficiency 98.6% European efficiency 98.3% <1W consumption during the night Safe DC and AC surge protection devices integrated Noise ≤ 29dB, Class-B electromagnetic radiation RCD protection function Reliable Product warranty of 10 years Natural cooling technology with heat sink Outdoor application of IP65   Supplier Part No: 01074303-005 Weight: 25 kg Rated Power: 15,000 W Min PPT Voltage: 200 V Max PPT Voltage: 950 V DC Startup Voltage: 200 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,080 V Max DC Power: 22,500 W Max AC Power (5 Minutes): 15,000 W Surge AC Power (1 Second): 16,500 W Max DC Current: 44 A Max DC Inputs: 4 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 4 Euro Efficiency: 98.65 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-17KTL-M2 Inverters - Main Units Rating: 17,000W Phases: 3 The Huawei SUN2000-17KTL-M2 17kW 3phase inverter has a maximum efficiency up to 98.6 with an adaptable and flexible triple MPPT. DC & AC lightning protection is integrated into the unit and the natural cooling effectively improves product reliability. Smart Maximum of 2 MPPT for versatile adaption to different module types or quantities built up with different alignments Up to 4 strings intelligent monitoring and fault detection Exceptionally wide MPPT range. RS 485 and USB ports for connectivity and data management Local graphic LCD and optional remote monitoring via the NetEco portal or app. Efficient Maximum efficiency 98.6% European efficiency 98.3% <1W consumption during the night Safe DC and AC surge protection devices integrated Noise ≤ 29dB, Class-B electromagnetic radiation RCD protection function Reliable Product warranty of 5 years, with the option to extend to up to 10.  Natural cooling technology with heat sink Outdoor application of IP65   Supplier Part No: 01074304-005 Weight: 25 kg Rated Power: 17,000 W Min PPT Voltage: 200 V Max PPT Voltage: 950 V DC Startup Voltage: 200 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,080 V Max DC Power: 25,500 W Max AC Power (5 Minutes): 18,700 W Surge AC Power (1 Second): 17,000 W Max DC Current: 44 A Max DC Inputs: 4 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 4 Euro Efficiency: 98.3 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-20KTL-M2 Inverters - Main Units Rating: 20,000W Phases: 3 The Huawei SUN2000-20KTL-M2 20kW 3phase inverter has a maximum efficiency up to 98.6 with an adaptable and flexible triple MPPT. DC & AC lightning protection is integrated into the unit and the natural cooling effectively improves product reliability. Smart Maximum of 2 MPPT for versatile adaption to different module types or quantities built up with different alignments Up to 4 strings intelligent monitoring and fault detection Exceptionally wide MPPT range. RS 485 and USB ports for connectivity and data management Local graphic LCD and optional remote monitoring via the NetEco portal or app. Efficient Maximum efficiency 98.6% European efficiency 98.3% <1W consumption during the night Safe DC and AC surge protection devices integrated Noise ≤ 29dB, Class-B electromagnetic radiation RCD protection function Reliable Product warranty of 10 years Natural cooling technology with heat sink Outdoor application of IP65   Supplier Part No: 01074305-007 Weight: 25 kg Rated Power: 20,000 W Min PPT Voltage: 200 V Max PPT Voltage: 950 V DC Startup Voltage: 200 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,080 V Max DC Power: 30,000 W Max AC Power (5 Minutes): 20,000 W Surge AC Power (1 Second): 22,000 W Max DC Current: 44 A Max DC Inputs: 4 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 4 Euro Efficiency: 98.3 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-36KTL-M3 Inverters - Main Units Rating: 36,000W Phases: 3 The Huawei SUN2000-36KTL-M3 36kW 3phase inverter has a maximum efficiency up to 98.7 with an adaptable and flexible quad MPPT. Type II DC & AC surge arrestors are integrated into the unit and natural cooling effectively improves product reliability. Product Features Smart 4 MPPTs for versatile adaptions to different layouts 8 strings intelligent monitoring and fast trouble-shooting Wide MPPT range. Integrated PID Recovery Efficient Maximum efficiency 98.7% European efficiency 98.4% <5.5W consumption during the night Safe DC switch integrated, safe and convenient for maintenance Type II surge arresters for both DC and AC Residual Current Detection (RCD) protection Arc Fault Protection Anti-islanding Protection Reliable No need for external fans with natural cooling technology Protection rating of IP66 5 year manufacturer warranty as standard: optional upgradable to 10 years. Note: This inverter has no screen and must be commissioned either by using the SUN2000 app on an Android phone and IOS or by connecting the unit to the Smart Logger. UK only: This inverter has been tested and certified according to G99, but only for units having most recent Firmware. Please check if the unit you are purchasing meets that criteria and if in doubt, please update the inverter firmware.  All residential and commercial inverters can now be monitored by FusionSolar. A Smartlogger is required for plants with more than 10 inverters. UK G100 Export Limitation possible with additional Power Management packages.  Supplier Part No: 01075485-001 Weight: 43 kg Rated Power: 36,000 W Min PPT Voltage: 200 V Max PPT Voltage: 1,100 V DC Startup Voltage: 200 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,100 V Max DC Power: 54,000 W Max AC Power (5 Minutes): 40,000 W Surge AC Power (1 Second): 40,000 W Max DC Current: 104 A Max DC Inputs: 8 Has DC Fuses: 0 Connector: MC4   Included Connectors: 0 Euro Efficiency: 98.4 % Transformer: None MPPT Quantity : 4 Has Integrated DC Switch: Yes Warranty: 5 years Data Sheet SUN2000-30-40KTL-M

Read more less

Part No: SUN2000-40KTL-M3 Inverters - Main Units Rating: 40,000W Phases: 3 The Huawei SUN2000-40KTL-M3 40kW 3phase inverter has a maximum efficiency up to 98.7 with an adaptable and flexible quad MPPT. Type II DC & AC surge arrestors are integrated into the unit and natural cooling effectively improves product reliability. Product Features Smart 4 MPPTs for versatile adaptions to different layouts 8 strings intelligent monitoring and fast trouble-shooting Wide MPPT range. Integrated PID Recovery Efficient Maximum efficiency 98.7% European efficiency 98.4% <5.5W consumption during the night Safe DC switch integrated, safe and convenient for maintenance Type II surge arresters for both DC and AC Residual Current Detection (RCD) protection Arc Fault Protection Anti-islanding Protection Reliable No need for external fans with natural cooling technology Protection rating of IP66 5 year manufacturer warranty as standard: optional upgradable to 10 years. Note: This inverter has no screen and must be commissioned either by using the SUN2000 app on an Android phone and IOS or by connecting the unit to the Smart Logger. UK only: This inverter has been tested and certified according to G99, but only for units having most recent Firmware. Please check if the unit you are purchasing meets that criteria and if in doubt, please update the inverter firmware.    Supplier Part No: 01075485 Weight: 43 kg Rated Power: 40,000 W Min PPT Voltage: 200 V Max PPT Voltage: 1,000 V DC Startup Voltage: 200 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,100 V Max DC Power: 40,000 W Max AC Power (5 Minutes): 44,000 W Surge AC Power (1 Second): 44,000 W Max DC Current: 104 A Max DC Inputs: 8 Has DC Fuses: 0 Connector: MC4   Included Connectors: 0 Euro Efficiency: 98.4 % Transformer: None MPPT Quantity : 4 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-5KTL-M1 Storage Systems - Hybrid Inverter The Smart Energy Center of Huawei is the perfect solution where three phase power is needed with the added benefit of having a HV battery connected as well.  Product Features Wide range on PV input  2 x MPPT inputs Single inverter with Three Phase output High voltage battery input Type II AC and DC surge protection  Arc Fault detection Anti-islanding protection Integrated PID recovery Compatible with Huawei Smart ESS battery 5KWh to 30KWh IP65   2019 Inter Solar Award Winner   Supplier Part No: 01074320-001 Weight: 17 kg Rated Power: 5,000 W Min PPT Voltage: 200 V Max PPT Voltage: 980 V DC Startup Voltage: 200 V DC Shutdown Voltage: 140 V Max Input Voltage: 1,100 V Max DC Power: 7,500 W Max AC Power (5 Minutes): 5,500 W Surge AC Power (1 Second): 5,501 W Max DC Current: 22 A Max DC Inputs: 2 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 2 Euro Efficiency: 97.5 % Transformer: HF MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-60KTL-M0 Inverters - Main Units Rating: 60,000W Phases: 3 Product Features Smart 12 strings with 6x MPPT intelligent monitoring and fast trouble-shooting Power Line Communication (PLC) supported Smart I-V Curve Diagnosis supported Safe DC disconnect integrated, safe and convenient for maintenance Residual Current Detection (RCD) protection Fuse free design Reliable Natural cooling technology Protection rating of IP65 Type II surge arresters for both DC and AC This inverter performs best when installed in cooler environments such as basement plant rooms. Please note this inverter can be set to standard 400V or medium voltage 480V grid depending on Grid Code chosen on commissioning. Please see the manual for details. Note: This inverter has no screen and must be commissioned either by using the SUN2000 app on an Android phone and IOS or by connecting the unit to the Smart Logger. UK only: This inverter has been tested and certified according to G99, but only for units having most recent Firmware. Please check if the unit you are purchasing meets that criteria and if in doubt, please update the inverter firmware.  All residential and commercial inverters can now be monitored by FusionSolar. A Smartlogger is required for plants with more than 10 inverters. UK G100 Export Limitation possible with additional Power Management packages. Supplier Part No: SUN2000-60KTL-M0Weight: 89 kgRated Power: 60,000 WMin PPT Voltage: 200 VMax PPT Voltage:1,000 VDC Startup Voltage: 200 VDC Shutdown Voltage: 200 VMax Input Voltage: 1,000 VMax DC Power: 70,000 WMax AC Power (5 Minutes): 66,000 WSurge AC Power (1 Second): 66,000 WMax DC Current: 132 AMax DC Inputs: 12Has DC Fuses: 0Connector: Amphenol H4Included Connectors: 12Euro Efficiency: 98.5 %Transformer: NoneMPPT Quantity : 6Has Integrated DC Switch: YesWarranty: 5 years Click Here For Specs

Read more less

Part No: SUN2000-8KTL-M1 Storage Systems - Hybrid Inverter The Smart Energy Center of Huawei is the perfect solution where three phase power is needed with the added benefit of having a HV battery connected as well.  Product Features Wide range on PV input  2 x MPPT inputs Single inverter with Three Phase output High voltage battery input Type II AC and DC surge protection  Arc Fault detection Anti-islanding protection Integrated PID recovery Compatible with Huawei Smart ESS battery 5KWh to 30KWh IP65   2019 Inter Solar Award Winner   Supplier Part No: 01074314-001 Weight: 17 kg Rated Power: 8,000 W Min PPT Voltage: 200 V Max PPT Voltage: 980 V DC Startup Voltage: 200 V DC Shutdown Voltage: 140 V Max Input Voltage: 1,100 V Max DC Power: 12,000 W Max AC Power (5 Minutes): 8,800 W Surge AC Power (1 Second): 8,801 W Max DC Current: 22 A Max DC Inputs: 2 Has DC Fuses: 0 Connector: Amphenol H4   Included Connectors: 2 Euro Efficiency: 98.6 % Transformer: HF MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

VARTA SILVER Dynamic A class of its own!  Be it technology, safety, service life or comfort: with the new SILVER dynamic, VARTA has put a premium on all-round maximum performance, offering an extensive range of types for almost every make of car. The new SILVER dynamic is the SUPERIOR HIGH PERFORMANCE BATTERY Other References VW: 000-915-105-AK All Prices Include VAT  Brand Varta Product Code I1 DIN 610 402 092 Range Varta Silver Voltage 12 Volts Technology Wet Capacity (C20) 110 Ah CCA (EN) 920 A Length 393 mm Width 175 mm Height inc. terms 190 mm Other References UK Ref 020, 610402092, 610 200, VW 1J0915105AK Guarantee 5 Years

Read more less

VARTA Promotive Black offers innovative VARTA expertise that makes it an excellent choice, delivering made-to-measure power output for older vehicles and those with lower energy requirements. Thanks to its tried-and-tested hybrid technology, the VARTA Promotive Black provides outstanding power reserves and performance - and is completely maintenance-free under normal usage conditions. With its vibration-resistant design and high cyclic stability, the VARTA Promotive Black is a reliable power source that will impress you right from the word "go", whether its used in HGVs, trucks, construction vehicles or agricultural vehicles. All Prices Include VAT  Brand Varta Voltage 12 Volts Technology Wet Capacity 120 Ah - 760CCA Length 510 mm Width 175 mm Height inc. terms 235 mm   Warranty 3 Years

Read more less

VARTA Promotive Black offers innovative VARTA expertise that makes it an excellent choice, delivering made-to-measure power output for older vehicles and those with lower energy requirements. Thanks to its tried-and-tested hybrid technology, the VARTA Promotive Black provides outstanding power reserves and performance - and is completely maintenance-free under normal usage conditions. With its vibration-resistant design and high cyclic stability, the VARTA Promotive Black is a reliable power source that will impress you right from the word "go", whether its used in HGVs, trucks, construction vehicles or agricultural vehicles. All Prices Include VAT  Brand Varta Voltage 12 Volts Technology Wet Capacity 120 Ah - 780CCA Length 347 mm Width 173 mm Height inc. terms 234 mm   Warranty 3 Years TYPE 663

Read more less

Part No: IMO-SI32-PEL64R-2 Switches - DC Isolators IMO - SI32 - DC Isolator  IMO Solar Isolators are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations must be equipped with DC Isolators in accordance with IEC 60364-7-712. 2 Pole (1 string) IP66 Enclosure  Grey Body with Black switch Switching times of less than 5ms IMO patented "Safelock" function Dimensions (mm): 180x98x107   Supplier Part No:SI32-PEL64R-2 Weight:0.5 kg Poles:2 Max Cable:10 mm2 Max Voltage:1,500 V Rated Current:32 A Rated Voltage:600 V Rated Current:32 A Rated Voltage:500 V Rated Current:27 A Rated Voltage:700 V

Read more less

Part No: IMO-SI16-PEL64R-4 Switches - DC Isolators IMO - SI16 - DC Isolator  IMO Solar Isolators are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations must be equipped with DC Isolators in accordance with IEC 60364-7-712. 4 Pole (2 string) IP66 Enclosure  Grey Body with Black switch Switching times of less than 5ms IMO patented "Safelock" function Dimensions (mm): 180x98x107   Supplier Part No:SI16-PEL64R-4 Weight:0.5 kg Poles:4 Max Cable:10 mm2 Max Voltage:1,500 V Rated Current:0 A Rated Voltage:0 V Rated Current:16 A Rated Voltage:600 V Rated Current:0 A Rated Voltage:0 V Rated Current:16 A Rated Voltage:800 V

Read more less

Part No: IMO-SI25-PEL64R-4 Switches - DC Isolators IMO - SI25 - DC Isolator  25A 600VDC IMO Solar Isolators are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations must be equipped with DC Isolators in accordance with IEC 60364-7-712. 4 Pole (2 string) IP66 Enclosure  Grey Body with Black switch Switching times of less than 5ms IMO patented "Safelock" function Dimensions (mm): 180x98x107   Supplier Part No:SI25-PEL64R-4 Weight:0.74 kg Poles:4 Max Cable:10 mm2 Max Voltage:1,500 V Rated Current:25 A Rated Voltage:600 V Rated Current:25 A Rated Voltage:800 V

Read more less

Part No: IMO-SI32-PEL64R-4   Switches - DC Isolators IMO - SI25 - DC Isolator  32A 600VDC IMO Solar Isolators are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations must be equipped with DC Isolators in accordance with IEC 60364-7-712. 4 Pole (2 string) IP66 Enclosure  Grey Body with Black switch Switching times of less than 5ms IMO patented "Safelock" function Dimensions (mm): 180x98x107   Supplier Part No:SI32-PEL64R-4 Weight:0.5 kg Poles:4 Max Cable:10 mm2 Max Voltage:1,500 V Rated Current:32 A Rated Voltage:800 V Rated Current:32 A Rated Voltage:600 V

Read more less

Part No: IMO-IS4P20-1P Switches - AC Isolators This part is a special offer made up of the following items: Part   1 x IMO-IS4P20 IMO Stag AC Isolator 4 Pole 20 Amp   Stag AC Isolator Switch  3 Pole Enclosed 20A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 125 W - 100 D - 85 D (including handle) - 120   Weight: 0.52 kg Rated Power: 4,600 W Poles: 3 Max Cable: 10 mm2 Max Voltage: 230 V Rated Current: 20 A Rated Voltage: 230 V

Read more less

Part No: IMO-IS4P20 Switches - AC Isolators Stag AC Isolator Switch  4 Pole Enclosed 20A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 125 W - 100 D - 85 D (including handle) - 120   Supplier Part No: IS4P20 Weight: 0.52 kg Rated Power: 13,840 W Poles: 4 Max Cable: 10 mm2 Max Voltage: 690 V Rated Current: 20 A Rated Voltage: 230 V

Read more less

Part No: IMO-IS4P32 Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 32A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 125 W - 100 D - 85 D (including handle) - 120  Supplier Part No: IS4P32 Weight: 0.52 kg Rated Power: 22,144 W Poles: 4 Max Cable: 10 mm2 Max Voltage: 690 V Rated Current: 32 A Rated Voltage: 415 V Rated Current: 32 A Rated Voltage: 230 V

Read more less

Part No: IMO-IS4P32-1P Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 32A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 125 W - 100 D - 85 D (including handle) - 120   Weight: 0.52 kg Rated Power: 22,144 W Poles: 3 Max Cable: 10 mm2 Max Voltage: 400 V Rated Current: 32 A Rated Voltage: 415 V Rated Current: 32 A Rated Voltage: 230 V Rated Current: 0 A Rated Voltage: 0 V

Read more less

Part No: IMO-IS4P100 Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 100A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 240 W - 160 D - 120 D including handle - 165   Supplier Part No:IS4P100 Weight:1.34 kg Rated Power:23,000 W Poles:4 Max Cable:35 mm2 Max Voltage:690 V Rated Current:100 A Rated Voltage:230 V Rated Current:100 A Rated Voltage:440 V

Read more less

Part No: IMO-IS4P125 Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 125A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 240 W - 160 D - 120 D including handle - 165   Supplier Part No:IS4P125 Weight:1.34 kg Rated Power:28,750 W Poles:4 Max Cable:35 mm2 Max Voltage:690 V Rated Current:125 A Rated Voltage:440 V Rated Current:125 A Rated Voltage:230 V

Read more less

Part No: IMO-IS4P150 Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 150A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 240 W - 160 D - 120 D including handle - 165   Supplier Part No:IS4P150 Weight:1.34 kg Rated Power:34,500 W Poles:4 Max Cable:35 mm2 Max Voltage:690 V Rated Current:150 A Rated Voltage:440 V

Read more less

Part No: IMO-IS4P40 Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 40A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 175 W - 115 D - 100 D including handle - 135   Supplier Part No:IS4P40 Weight:0.75 kg Rated Power:9,200 W Poles:4 Max Cable:10 mm2 Max Voltage:690 V Rated Current:40 A Rated Voltage:230 V

Read more less

Part No: IMO-IS4P63 Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 63A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 175 W - 115 D - 100 D including handle - 135   Supplier Part No:IS4P63 Weight:0.75 kg Rated Power:14,490 W Poles:4 Max Cable:16 mm2 Max Voltage:690 V Rated Current:63 A Rated Voltage:230 V Rated Current:63 A Rated Voltage:440 V

Read more less

Part No: IMO-IS4P80 Switches - AC Isolators AC Isolator Switch  4 Pole Enclosed 80A AC Switch Isolator  IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 240 W - 160 D - 120 D including handle - 165   Supplier Part No:IS4P80 Weight:1.34 kg Rated Power:18,400 W Poles:4 Max Cable:35 mm2 Max Voltage:690 V Rated Current:80 A Rated Voltage:440 V Rated Current:80 A Rated Voltage:230 V

Read more less

Part No: GSE-CLAMP-SINGLE-H16-V2023-BLA Mounting - Module Clips Keywords: GSECLAMPSINGLEH16BLA, GSE, PV Mounting, Module Clip.   Supplier Part No: ART105897 Weight: 0.023 kg Clip Type: 199 Clip H: 46 mm Clip B1: 30 mm Clip Colour: Black

Read more less

Part No: SLT-129060-000 Mounting - Rail Connectors Schletter Solo and Solo Light internal rail connector. Used to join two rails together to create longer spans. This product contains 1x aluminium parts. Screws are sold seperately.  Recommended on trapezoidal roofs where rail alignment is a priority. Especially useful when using single fix trapezoidal fixings where standard external connectors could prevent the rails from sitting properly on the roof crests. Warning:  943755-925 Screws are not included, please use 4 x 943755-925 per two solo rail connectors. Important SA - Required - 4 x Self Drilling Screw 5.5 x 25 A2 Part No. SLT-943755-925 - For Connectors. Supplier Part No: 129060-000 Weight: 0.07 kg

Read more less

Part No: SLT-129060-000-KIT Mounting - Rail Connectors This part is made up of the following items: 2 x SLT-129060-000 Insertion connector Solo / Profile   4 x SLT-943755-925 Self Drilling Screw 5.5 x 25 A2 - For Connectors   Schletter Solo And Solo Light Internal Rail Connector Kit Schletter Solo and Solo Light internal rail connector kit. Used to join two rails together to create longer spans. This product contains 2x aluminium parts and 4 screws.  Recommended on trapezoidal roofs where rail alignment is a priority. Especially useful when using single fix trapezoidal fixings where standard external connectors could prevent the rails from sitting properly on the roof crests.   Weight: 0.164 kg

Read more less

Part No: SLT-129078-001 Mounting - FixGrid Interior rail connector for FlatGrid and FixGrid kit.   Supplier Part No: 129078-001 Weight: 0.8 kg

Read more less

Course Duration: 5 DaysStart Time: 09:00amFinish Time: 04:30pm This 5-day course will provide you with the practical and theoretical experience needed to succeed on the initial and Periodic Electrical Inspection and Testing (2391-52) - 5.5 Days Assessment course. Gain the knowledge and understanding to excel in electrical inspection and testing with our comprehensive 5-day fundamentals course. This course will teach you to safely isolate electrical circuits and installations for three-phase and single-phase systems. You will learn the requirements for initial verification, inspection & testing and commissioning before energizing the circuits. The importance of completing installation certificates and associated documentation will also be covered, as well as safety considerations and regulations. This includes factors that affect conductor resistance values, common earth fault loop paths, and methods for verifying protection. Additionally, you will learn about the frequency of testing, routine checks, and specific tests for phase rotation. Take the guesswork out of safely working with three-phase and single-phase electrical systems. Gain valuable insights on initial verification, testing, and commissioning of circuits while adhering to safety regulations and completing necessary documentation. Master conductor resistance, earth fault loops, and protection verification. Plus, discover the optimal frequency for testing and learn essential routine checks and phase-specific tests. Required Books for this qualification BS 7671 IET Wiring Regulations - Amazon Guidance Note 3: Inspection & Testing - Amazon Codebreakers: a Guide to Coding Observations for Electrical Installation Condition Reports (EICRs) - Amazon

Read more less

Course Duration: 5 Days Classroom & 1/2 Day Practical Assessment* Start Time: 09:00amFinish Time: 04:30pm *Your 1/2 Day Practical Assessment date will be arranged with you during your time at the centre.  What Is Involved In Studying This Course? This qualification delivers the specialist knowledge and skills you need, including appropriate legislation, inspection and testing techniques, completing and issuing certificates or reports and understanding of results and measurements. 2391-52 Combined Initial Verification and Periodic Inspection and Testing: Intended for experienced electricians who have never gained formal qualifications in inspection and testing or who may wish to update and reaffirm their skills. Assessment will be through a multiple-choice on-line test and a practical task. What Careers Can This Lead To? This qualification is intended for practising electricians who want to expand their skills and knowledge in the area of Initial Verification and/or Periodic Inspection and continue their professional development.On successful completion learners can also progress on to the City & Guilds Level 4 Award in the Design and Verification of Electrical Installations. Pre-requisites This qualification is aimed at electricians working within domestic and/or non-domestic premises and they shall hold as a minimum; A Level 3 Award in the Requirements for Electrical Installations BS7671 (current edition)and A good understanding of how to Inspect & Test Electrical Installations. If you do not, we recommend you also undertake a Fundamentals of Inspection & Testing Course beforehand  Required Books for this qualification BS 7671 IET Wiring Regulations - Amazon Guidance Note 3: Inspection & Testing - Amazon Codebreakers: a Guide to Coding Observations for Electrical Installation Condition Reports (EICRs) - Amazon

Read more less

Part No: AM550-CT Meters - Three Phase Generation Meters this next generation AM550 smart meter, with an innovative platform approach enables seamless integration of next generation smart metering functions into the smart grid.  The specific model of this meter is AM550 It includes these features: Universal standardized transparent passthrough communication interface  Optimized new metrology base with a powerful “Measure Everything” measuring concept  Modular communication on WAN (P3) and HAN (P1) level  FW upgradeability of communication modules (P3 port)  Backward compatible PLC modules  Flexible memory capacity availability  Extended set of embedded Smart Grid functions Integrated high level security mechanisms Flexible set of input/output options  Sub-metering support and data forwarding over various HAN and WAN communication paths UK:This meter includes a roaming SIM that is pre-registered with Meter Online. In order to choose a suitable data subscription and activate the SIM, go to https://secure.ss4meteronline.co.uk/  PLEASE NOTE: This meter does not include CT clamps and these should be sourced separately. 3 x split CT's (SCT24) are required for use with this meter. Supplier Part No:AM550-CT200 Weight:1.5 kg

Read more less

Part No: ISK-MT174 Meters - Three Phase Generation Meters The MT174 electronic three-phase meters are designed for measurement and registration of active, reactive and apparent energy and demand in three-phase four-wire networks Multi-tariff c\w internal time switch 120A Three Phase/Single Phase kWh meter OFGEM Approved - Import/Export Energy Tariff control input Small size modern design Pulse output Max Demand Low Profile   Supplier Part No: MT174-Direct Weight: 1 kg

Read more less

Part No: ISKRA-MT174-CT Meters - Three Phase Generation Meters Iskra MT174 CT CT operated 200\5 3 Phase 4 wire Import\Export MID approved Pulsed Output   Three-Phase Static Electricity Multi Tariff Meter with Maximum Demand Indicator and Load-profile   THIS METER REQUIRES CTs TO OPERATE.      Supplier Part No:MT174CT 200/5 Weight:1 kg

Read more less

Dimensions: 367.00 x 176.00 x 380.00 mm (H x W x L) Weight: 57.00 kg List No: 1403 Voltage: 12 AH (C20): 200 AH (C100): 212 AH (C5): 157 Technology: AGM Founded in 1925 by George Godber and Carl Speer, Trojan Battery Company has become the world's leading manufacturer of deep-cycle Solar and Motive batteries. Trojan produces a broad range of energy storage solutions including deep-cycle Flooded, AGM, Gel and Lithium batteries.   DEEP-CYCLE AGM BATTERIES with C-Max Technology™ Trojan has developed AGM batteries with C-Max Technology™ for a wide range of applications that require deep-cycling power such as golf, utility, NEV and low-speed vehicles, as well as hunting buggies. These batteries deliver increased total energy output, maximised sustained performance, consistent quality, and enhanced durability. C-MAX TECHNOLOGY INCORPORATES A WIDE RANGE OF FEATURES NOT FOUND IN MANY AGM BATTERY OFFERINGS: _ Proprietary paste maximises sustained performance and increases total energy. _ Unique separator protects against stratification and extends battery life. _ Plastic polymer case is extremely durable and provides higher battery cell performance to ensure reliability. _ Flame arrestors provide maximum safety.

Read more less

All Batteries are Made By Leading Manufacturers    Suitable for EZGO Golf Carts, Access Platforms, Industrial Cleaning machines, G Whizz Car, Solar panels, Marine use and  much more. Description Trojan Battery Company is the world leader in deep cycle battery technology. Since 1925, Trojan has been a pioneer in the development of superior deep cycle batteries. Decades of experience, on-going research and dedication go into every deep cycle battery we manufacture. You can depend on Trojan to deliver reliable, long lasting, continuous power and exceptional value. Trojan's dominance in deep cycle products is  the result of years of R & D investment, continuous product testing and adherence to strict manufacturing procedures. Trojan produce CAST grids with heavy WIRE and FRAME design. To each grid, Trojan applies its specially formulated Alpha Plus paste formulation. It?s the optimized paste density of this proprietary formula which provides our products with their superior cycle life. Another Trojan exclusive is its curing process. Once the grids are pasted, they are placed in specially constructed curing rooms which are temperature and humidity controlled. Then they are slowly cured. This provides Trojan deep cycle plates with the most tenacious active material. Once the plates are cured, they are then hand assembled, sealed and formed. Each step is completed under rigorous quality control standards to insure greater cycle time and battery life. Benefits Maximum run time Greater cycle life Lower electricity costs All Prices Include VAT  Click Here For Spec Sheet Brand Trojan Voltage 12 Volts Technology Wet / Vented Capacity 185Ah Length 381 mm Width 178 mm Height inc. terminals 371 mm Weight 48 KG Capacity (C5) 152 Ah Capacity (C10) 170 Ah Capacity (C20) 185 Ah Capacity (C100) 205 Ah Warranty 1 year
