EcoFlow OCEAN 2 Plus 10kW Single-Phase Hybrid Inverter
Product form
Out of stock
Fast shipping
Collection available More info
Overview
Details
Designed to make installation super quick and easy, the EcoFlow OCEAN 2 Plus 10kW hybrid inverter is lightweight and compact, and seamlessly integrates with up to six battery modules. Every step of the installation process has been streamlined, including integrated handles, an inbuilt smart meter, and a pre-installed whole-home backup connection, to save time during setup and ensure installers can move on quickly to the next job.
Through the user-friendly EcoFlow app, homeowners can keep track of energy usage and schedule battery charging but the HEMS Intelligent Mode optimises the system too to reduce much of the maintenance. For safety, six layers of passive protection and four layers of active protection prevent overheating and fire risks, while the IP66 ingress protection rating means units can be positioned outside if necessary.
Key features:
- Compact 10kW single-phase hybrid inverter designed to integrate seamlessly with battery modules
- Consists of three MPPTs
- Compatible with OCEAN 2 and the older PowerOcean batteries (up to six OCEAN 2 modules or four PowerOcean modules when floor-mounted, or three modules of any type when wall-mounted)
- Lightweight to make installation easier and safer on site
- Inbuilt handles, captive side screws and no decorative covers on the side to save at least 20 minutes of installation time
- Inbuilt smart meter saves around 50 minutes when installing
- Whole-home backup connection, which ensures lights and critical appliances stay on during grid outages, is integrated to save around 60 minutes during installation
- EcoFlow HEMS Intelligent Mode optimises the system to determine when to charge and when to use stored energy
- Open ecosystem for compatibility with a range of smart home devices
- Six layers of passive protection including thermal and fire-resistant insulation, short-circuit protection and fire prevention module
- Four layers of active protection including temperature monitoring and cloud BMS early warning
- Mountable on the wall or floor
- Bluetooth, Wi-Fi, RS485 and CAN connectivity
- Maximum efficiency: 97.6%
- Ingress protection: IP66
- Operating temperature: -20°C to 55°C
- Dimensions: 680mm x 406.5mm x 203mm
- Weight: 36.5kg
- 15-year warranty
Scale Your Energy Storage Anytime
Delivers True Whole-Home Backup You Can Rely On
OCEAN 2 Plus delivers true whole-home backup, supporting higher household loads during outages—from essential appliances to high-power devices. It also supports third-party inverter connections on the backup side, offering greater flexibility for existing solar installations.
72A Bypass
Supports higher household loads during outages.
Integrated Backup
No additional gateway required.
Keep Your Home Running Without Interruption
OCEAN 2 Plus instantly transitions to backup power the moment a grid outage occurs. Lights, appliances, and home systems keep running smoothly—without flicker, interruption, or manual intervention.
0 ms*
Load-side switchover
* The 0 ms transfer time applies under the following conditions: compliance with local grid regulations. In the open-circuit state of the power grid, total load power does not exceed the rated output backup power under stable grid conditions.
One Tap. Energy Savings up to 77.6% with Intelligent HEMS
EcoFlow HEMS introduces Intelligent SmartEarning Mode—a fully automated way to reduce electricity bills and boost solar efficiency. It intelligently charges your battery when electricity prices are low and powers your home from stored energy when rates are high. By leveraging dynamic tariff integrations, this mode ensures that every charging and discharging decision is made with cost in mind.
High Efficiency. Designed to Save, All Day Long.
Not all savings come from big moments.
OCEAN 2 is designed to reduce energy loss even during light-load operation—quietly saving power whenever your home needs less.
From standby hours to low-demand periods, efficiency is built into every moment, turning small savings into meaningful long-term returns.
Up to 6,000 kWh Saved
Estimated energy savings over the system’s lifespan
- Estimated energy savings are calculated by comparing 50W light-load power with a typical system consuming 160W when the battery is discharging. Figures are based on internal testing and typical household usage scenarios. Actual results may vary.
10 Layers of Protection From Every Component to the Entire System
Safety in OCEAN 2 is engineered from the inside out.
With 6 layers of passive protection and 4 layers of active protection, every critical element is continuously safeguarded—from individual components and battery cells to the enclosure and the system as a whole.
Flexible Installation for Any Home
Compact, lightweight, and installation-friendly, OCEAN 2 Plus is designed to simplify system placement in almost any home.
Ultra-compact
279 mm height | Only 0.15 m² footprint
Ultra-light
46 kg battery pack | Easy on-site handling
Outdoor-Ready
IP66 protection | Suitable for indoor or outdoor installation
Flexible Mounted Option
Wall-mounted & floor-mounted | Flexible installation to fit different spaces
Designed to Work Across Generations
Cross-Gen System Compatibility
Mix Old & New Battery Packs
Built to Last. Ready for Any Weather.
Engineered for long-term stability in harsh outdoor environments—OCEAN 2 delivers consistent performance, whatever the conditions.
