Description
DOWNLOAD SPEC SHEET
The 45kw/90kw Battery Storage Unit is a tailored energy solution designed to provide reliable and efficient power. This Powerbox solution ensures a sustainable and uninterrupted power supply. Each unit can be charged by Generator or Mains Power & has generator stop/start function built-in. Solar Panels can also be incorporated to supply renewable energy for charging.
The Powerbox Battery Storage Container is a cutting-edge solution for efficient and reliable energy storage. With its robust design, advanced features, and versatile applications, it is an ideal choice for anyone looking to enhance their energy management and sustainability efforts.
General Data
-
Model: Powerland Powerbox 45/90
-
Dimensions: 2000 x 2000 x 2000 mm
-
Weight: Approx. 2000 kg
Inverter Specifications
-
Type: 3-Phase Inverter
-
Rated Power: 1 x 15 kVA per phase (45 kVA total)
-
Maximum Output: 45 kVA (3-phase)
-
AC Output Voltage Range: 200-400 VAC ± 2%
-
Frequency Range: 50 Hz ± 0.1%
-
Usable Stored Power: 90 kWh
-
Maximum Feed Through Current: 3 x 100 A
-
AC Input Voltage Range: 38 - 66 V
-
Input Frequency: 45 - 65 Hz
-
Weight (per inverter): 3 x 80 kg
-
Dimensions (per inverter): 810 x 405 x 217 mm
-
Connections:
- 2 x 16A (single-phase sockets)
Battery Specifications
-
Type: Lithium LiFePO4
-
Configuration: 9 x 100 Ah modules, 48-51 V
-
Usable Capacity: 90 kW
-
Nominal Output: 5 kW
-
Depth of Discharge: 100%
-
Battery Management: Yes (with Active Balancing)
-
Interfaces: RS485/CAN
-
Number of Cycles: 3,500 (+25°C; 0.45C)
-
Temperature Range: -20°C to +60°C
-
Weight: 42 kg
-
Dimensions: 442 x 431 x 177 mm
-
![Several different types of electrical equipment
AI-generated content may be incorrect.]()
Design Life: 15 years
