Features:
- Integrated 4 MPPTs for multiple array orientations
- Up to 50A max charge/discharge current
- String current up to 20A, perfectly match large current modules
- 10 second 200% surge power backup overload capability
- Supports Max 6 pcs in parallel
- Supports Unbalanced and Half-Wave Loads on both the Grid and Backup Port
- Supports peak shaving control in both "self-use" and "generator" mode
- 6 customisable charge/discharge time settings
- Automatic UPS switching
- Intelligent AC coupling scheme, easily upgrade existing grid-connected systems
Note: Including 3 current sensors for direct connection to the inverter
Supplier Part No:S6-EH3P15K-H-EUWeight:31.7 kgRated Power:15,000 WMin PPT Voltage:200 VMax PPT Voltage:850 VDC Startup Voltage:160 VDC Shutdown Voltage:160 VMax Input Voltage:1,000 VMax DC Power:24,000 WMax AC Power (5 Minutes):15,000 WSurge AC Power (1 Second):15,000 WMax DC Current:52 AMax DC Inputs:4Has DC Fuses:0Connector:MC4 Included Connectors:0Euro Efficiency:97.7 %Transformer:NoneMPPT Quantity :2Has Integrated DC Switch:NoWarranty:5 years
