Victron Energy SmartSolar MPPT 150/45 – SCC115045212

Description

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.



MPPT: Ultra Fast Maximum Power Point Tracking

By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.

Remote Monitoring and Control

Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations – even when there is no internet connection or phone signal nearby – you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally.

Bluetooth Smart built-in

The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.

VE.Direct

For a wired data connection to a Color Control GX, other GX products, PC or other devices

Advanced Maximum Power Point Detection in case of partial shading conditions

If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.

Outstanding conversion efficiency

No cooling fan. Maximum efficiency exceeds 98%. Full output current up to 40°C (104°F).

Flexible charge algorithm

Fully programmable charge algorithm (see the software page on our website), and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details).

Extensive electronic protection

  • Over-temperature protection and power derating when temperature is high.
  • PV short circuit and PV reverse polarity protection.
  • PV reverse current protection.

Internal temperature sensor

Compensates absorption and float charge voltage for temperature.

Optional external battery voltage and temperature sensing via Bluetooth

A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers.







                             CLICK HERE FOR SPEC SHEET

                            Brand

                            Victron Energy

                            Manufacturer Part Number

                            SCC115045212

                            GTIN

                            8719076053026

                            Battery Voltage

                            12/24/48V Auto Select (software tool needed to select 36V)

                            Rated Charge Current

                            45A

                            Nominal PV power

                            12V: 650W / 24V: 1300W / 36V: 1950W / 48V: 2600W

                            Max. PV short circuit current

                            50A

                            Maximum PV Open Circuit Voltage

                            150V absolute maximum coldest conditions 145V start-up and operating maximum

                            Maximum efficiency

                            98%

                            Charge Algorithm

                            multi-stage adaptive (eight pre-programmed algorithms)

                            Data Communication Port

                            VE.Direct

                            Protection Category

                            IP43 (electronic components), IP22 (connection area)

                            Dimensions

                            H130 x W186 x D70mm

                            Weight

                            1.25Kg

                            Warranty

                            5 Years


                            Product form

                            A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology,... Read more

                            £237.23 Exc. VAT
                            £284.68 Inc. VAT
