HANCHU Low Voltage Battery 16kWh

Premium LiFePO4 Cells

Lithium iron phosphate cell chemistry designed for reliable residential energy storage.

7-LAYER BMS PROTECTION

Intelligent battery management system with seven layers of safety protection.

Aerosol Fire Suppression System

Thermal aerosol fire suppression combined with an integrated pressure relief valve.

WALL OR FLOOR MOUNTED

Flexible installation options with integrated wheels for easier positioning in different property and plant-room environments.

Scalability

Supports up to 16 batteries in parallel, with automatic battery identification to simplify setup and commissioning.

IP66 + C5-M PROTECTION

IP66 ingress protection with C5-M corrosion resistance for demanding environments.

Smart Monitoring with iESS

The intelligent iESS platform continuously monitors battery performance, employing both hardware and software solutions to ensure operational safety and efficiency.

Octopus Tariff Integration

Compatible with Auto Octopus energy pricing, reducing energy costs by utilising cheaper rates.

Smart Weather Compensation

Automatically adjusts settings in response to weather conditions to maximise energy efficiency.

• Cell Type: LFP (LiFePO4)
• Nominal Energy: 16kWh
• Maximum Parallel Number: 16
• Nominal Voltage: 51.2V
• Operating Voltage Range: 43.2-57.6V
• Dimension (W*D*H) (mm): 410*240*870 (excluding wheels)
• Weight: 120Kg
• Charging / Discharging Temperature: -20℃ to ~55℃
• Depth of Discharge: 95% DoD
• Nominal Charge/Discharge Current: 160A
• Max Charge / Discharge Current: 200A (90min, 25℃)
• Maximum Parallel Number: 16
• Ingress Protection Degree: IP66
• Corrosion Category: C5-M
• Cooling Type: Natural convection
• Humidity: ≤95%
• Installation: Wall-mounted / Floor-mounted
• Altitude: 3000m (>2000m derating)
• Communication: CAN/RS485/WIFI/Bluetooth/4G (Optional)
• Battery Safety: IEC 62619/CE-EMC/EN 62040/UN38.3
• Warranty: 12 years
