INVERTERS FOR SOLAR / BATTERY STORAGE

This cable is intended for on/off control of the Skylla-i when the source signal is high when the Skylla-i must be on, and low or free floating when Skylla-i must be off. Brand Victron Energy Manufacturer Part Number ASS030550400 Max. Input Voltage 70V Warranty 5 Years

Read more less

Open transition transfer The Filax is an open transition (break before make) transfer switch. The maximum load transfer time is 16ms. The load is normally supplied by the priority source, and is transferred to the alternate source if: The voltage of the priority source drops below the threshold value. The frequency of the priority source drops below the low frequency threshold value, or increases beyond the high frequency threshold value. Reverse transfer from the alternate source to the priority source is initiated when the priority source has operated within the voltage and frequency reverse switching limits during 30s. Brand Victron Energy Manufacturer Part Number SDFI0000110 Maximum Current 16 A Ingress Protection IP65 Dimensions (Including Terminals) H120 x W255 x D75mm Weight (kg) 0.8 Warranty 5 Years

Read more less

Temperature sensing is needed when LFP lithium batteries are charged at low temperatures. The charge current to a lithium battery has to be reduced once the battery temperature drops below 5 degrees and the charge current has to stop when the temperature drops below zero. The CAN-bus Temp. Sensor takes care of this. It measures the lithium battery temperature and sends this to the Buck-Boost DC/DC converter. The Buck-Boost DC/DC converter will reduce or stop charge when the battery temperature drops too low. In addition to this, the CAN-bus Temp. Sensor can also be connected to the temperature sensor terminal in a Multi or Quattro, so the Multi or Quattro can reduce or stop charging when the battery temperature drops too low. Brand Victron Energy Manufacturer Part Number ASS000200100 Supply voltage 4.36VDC Electricity consumption 60 mA (@13.6V) Alarm output (pin 5) 350 mA Open connector (switches to GND/Earth) Dimensions L57.6 x W40 x H15.8mm (incl. connectors) Weight 0.012Kg Warranty 5 Years

Read more less

Remote on-off The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by for example the engine run/stop switch (see manual).  Adjustable output voltage: can also be used as a battery chargerFor example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.  All models are short circuit proof and can be paralleled to increase output currentAn unlimited number of units can be connected in parallel.  IP43 protectionWhen installed with the screw terminals oriented downwards.  Screw terminalsNo special tools needed for installation. Input fuseOn 12V and 24V input models only.  PLEASE CLICK HERE FOR SPEC SHEET Brand Victron Energy Manufacturer Part Number ORI241240110 Input Voltage Range 20-35V Under Voltage Shutdown 14V Under Voltage Restart 15V Nominal Output Voltage 12.2V Output Voltage Adjust Range 10-15V Short Circuit Output Current 60A Cont. Output Power at 25°C 430W DC Connection Screw Terminals Protection Category IP43 Dimensions H130 x W186 x D80 mm Weight (kg) 1.8 Warranty 5 Years

Read more less

Adjustable output voltage: can also be used as a battery chargerFor example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.  All models are short circuit proof and can be paralleled to increase output currentAn unlimited number of units can be connected in parallel.  IP43 protectionWhen installed with the screw terminals oriented downwards.  Screw terminalsNo special tools needed for installation. Input fuseOn 12V and 24V input models only. Brand Victron Energy Manufacturer Part Number ORI484810110 Input Voltage Range 32-70V Under Voltage Shutdown 28V Under Voltage Restart 30V Nominal Output Voltage 48.2V Output Voltage Adjust Range 40-60V Short Circuit Output Current 17A Cont. Output Power at 25°C 120W DC Connection Screw Terminals Protection Category IP43 Dimensions H100 x W113 x D47mm Weight (kg) 0.42 Warranty 5 Years

Read more less

Adjustable output voltage: can also be used as a battery chargerFor example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.  All models are short circuit proof and can be paralleled to increase output currentAn unlimited number of units can be connected in parallel.  IP43 protectionWhen installed with the screw terminals oriented downwards.  Screw terminalsNo special tools needed for installation. Input fuseOn 12V and 24V input models only. Brand Victron Energy Manufacturer Part Number ORI484841110 Input Voltage Range 40-70V Under Voltage Shutdown 28V Under Voltage Restart 30V Nominal Output Voltage 48.2V Output Voltage Adjust Range 40-60V Short Circuit Output Current 25A Cont. Output Power at 25°C 430W DC Connection Screw Terminals Protection Category IP43 Dimensions H130 x W186 x D70mm Weight (kg) 1.6 Warranty 5 Years

Read more less

For use in dual battery systems in vehicles or on boats where the (smart) alternator and the start battery are used to charge the service battery. The unit can be monitored and programmed via Bluetooth and can be remotely controlled via a remote on/off switch and has an engine running detection mechanism. The Orion Tr-Smart charger can be used in 12V or 24V systems and is suitable for both lead acid and lithium batteries. Models are available up to 400W and unlimited multiple units can be connected in parallel to increase output power. Suitable for high temperatures up to 55°C with a full rated output up to 40°C.   Features Bluetooth Smart enabled Any Bluetooth enabled smart phone, tablet or other device can be used to monitor, to change settings and to update the charger when new software features become available. Fully programmable Battery charge algorithm (configurable) or fixed output. Smart alternator compatibility: engine running detection mechanism. Adaptive 3-stage charge algorithm: bulk – absorption – float For lead acid batteries it is important that during shallow discharges the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge the absorption time is automatically increased to make sure that the battery is completely recharged.  For lithium batteries absorption time is fixed, default 2 hours. Alternatively, a fixed output voltage can be chosen. Remote on-off A remote on/off switch or relay contact can be connected to a two-pole connector. Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example). All models are short circuit proof and can be paralleled to increase output current An unlimited number of units can be connected in parallel. High temperature protected The output current will reduce at high ambient temperature. IP43 protection When installed with the screw terminals oriented downwards. Screw terminals No special tools needed for installation. Input fuse (not replaceable) Brand Victron Energy Manufacturer Part Number ORI242428120 Input Voltage Range 16-35V Under Voltage Shutdown 14V Under Voltage Restart 15V Nominal Output Voltage 24.2V Output Voltage Adjust Range 20-30V Cont. Output Power at 25°C (W) 320W Cont. Output Power at 40°C (W) 280W Efficiency 89% DC Connection Screw Terminals Protection Category IP43 Dimensions H130 x W186 x D70mm Weight (kg) 1.3 Warranty 5 Years

Read more less

Remote on-off connector on the high power models The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by the engine run/stop switch. All models with adjustable output can also be used as a battery charger For example to charge a 12 Volt starter or accessory battery in an otherwise 24 Volt system. All models with adjustable output can be paralleled to increase output current Up to five units can be connected in parallel Brand Victron Energy Manufacturer Part Number ORI110123610 Input Voltage Range 60-140V Output Voltage 12.5V Galvanic Isolation No Dimensions H82 x W132 x D190mm Weight (kg) 1.4 Warranty 5 Years

Read more less

Brand Victron Energy Manufacturer Part Number ASS030520115 GTIN 8719076019527 Weight 0.06Kg Warranty 5 Years

Read more less

Liquid crystal display For status monitoring and set-up Day/night timing of the load output This option allows for a pre-set ON-time after dusk. Programmable battery charge algorithm Preprogrammed algorithms for AGM, GEL, Flooded or LiFePO4 batteries (with internal BMS only) Two 5 Volt USB outputs Maximum current (both outputs combined): 2A Brand Victron Energy Manufacturer Part Number SCC040010050 GTIN 8719076046233 Battery Voltage 48V Rated Charge Current 10A Maximum Solar Voltage 100V Load Output Manual control + low voltage disconnect + timer Grounding Common positive IP Rating IP20 Dimensions H101 x W184 x D47mm Weight 0.3Kg Warranty 5 Years

Read more less

 Liquid crystal display For status monitoring and set-up Day/night timing of the load output This option allows for a pre-set ON-time after dusk. Programmable battery charge algorithm Preprogrammed algorithms for AGM, GEL, Flooded or LiFePO4 batteries (with internal BMS only) Two 5 Volt USB outputs Maximum current (both outputs combined): 2A   Brand Victron Energy Manufacturer Part Number SCC040020050 GTIN 8719076046240 Battery Voltage 48V Rated Charge Current 20A Maximum Solar Voltage 100V Load Output Manual control + low voltage disconnect + timer Grounding Common positive IP Rating IP20 Dimensions H101 x W184 x D47mm Weight 0.3Kg Warranty 5 Years

Read more less

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, BlueSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. BlueSolar maintains battery health, extending its life.   Features Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30 % compared to PWM charge controllers and by up to 10 % compared to slower MPPT controllers. Advanced Maximum Power Point Detection in case of partial shading conditions If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP. Outstanding conversion efficiency No cooling fan. Maximum efficiency exceeds 98 %. Flexible charge algorithm Fully programmable charge algorithm, and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details). Extensive electronic protection Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection. Internal temperature sensor and optional external battery voltage, temperature and current sensing via Bluetooth A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature (and current, in case of a BMV-712 or a SmartShunt) to one or more BlueSolar Charge Controllers. (VE.Direct Bluetooth Smart dongle needed) Real-time data display options Color Control GX or other GX devices: see the Venus documents on our website. A smartphone or other Bluetooth-enabled device: VE.Direct Bluetooth Smart dongle needed.  CLICK HERE FOR SPEC SHEET Brand Victron Energy Manufacturer Part Number SCC010045200 GTIN 8719076025436 Battery Voltage 12/24/48V Auto Select (software tool needed to select 36V) Rated Charge Current 45A Nominal PV Power, 12V 650W Nominal PV Power, 24V 1300W Max. PV Short Circuit Current 50A Maximum PV Open Circuit Voltage 150V absolute maximum coldest conditions 145V start-up and operating maximum Efficiency 98% Charge Algorithm Multi-stage adaptive Data Communication Port VE.Direct IP Rating IP43 (electronic components), IP22 (connection area) Dimensions H185 x W250 x D95mm Weight 3Kg Warranty 5 Years

Read more less

Features Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers. Advanced Maximum Power Point Detection in case of partial shading conditions If partial shading occurs, two or more maximum power points (MPP) may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP. Outstanding conversion efficiency No cooling fan. Maximum efficiency exceeds 99%. Flexible charge algorithm Fully programmable charge algorithm, and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details). Extensive electronic protection Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection. Internal temperature sensor Compensates absorption and float charge voltage for temperature. Optional external battery voltage, temperature and current sensing via Bluetooth A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature (and current, in case of a BMV 712 or a SmartShunt) to one or more BlueSolar Charge Controllers. (VE.Direct Bluetooth Smart dongle needed) VE.Can: the multiple controller solution Up to 25 units can be synchronised with VE.Can VE.Direct or VE.Can For a wired data connection to a Color Control GX, other GX products, PC or other devices Remote on-off To connect for example to a VE.BUS BMS. Programmable relay Can be programmed to trip on an alarm, or other events. Optional: SmartSolar pluggable LCD display Simply remove the rubber seal that protects the plug on the front of the controller, and plug-in the display. Brand Victron Energy Manufacturer Part Number SCC125070441 GTIN 8719076050889 Battery Voltage 12/24/48V Auto Select (36V: manual) Rated Charge Current 70A Nominal PV Power, 12V 1000W Nominal PV Power, 24V 2000W Max. PV Short Circuit Current 35A Maximum PV Open Circuit Voltage 250V absolute maximum coldest conditions | 245V start-up and operating maximum Efficiency 99% Charge Algorithm multi-stage adaptive (eight preprogrammed algorithms) or user defined algorithm Data Communication Port VE.Can IP Rating IP43 (electronic components), IP22 (connection area) Dimensions H185 x W250 x D95mm Weight 3Kg Warranty 5 Years

Read more less

Features Remote Monitoring and Control Remotely control and monitor the extensive features of your BlueSolar MPPT charger by attaching a bluetooth dongle and pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet with a GX device, the Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both VictronConnect and VRM are free to use. For remote installations – even when there is no internet connection nearby – you may be able to monitor your MPPT by connecting the GlobalLink 520. Bluetooth Smart built-in The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers. Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers. Advanced Maximum Power Point Detection in case of partial shading conditions If partial shading occurs, two or more maximum power points (MPP) may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative SmartSolar algorithm will always maximize energy harvest by locking to the optimum MPP. Outstanding conversion efficiency No cooling fan. Maximum efficiency exceeds 98%. Flexible charge algorithm Fully programmable charge algorithm (see the software page on our website), and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details). Extensive electronic protection Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection. Internal temperature sensor Compensates absorption and float charge voltage for temperature. Optional external battery voltage, temperature and current sensing via Bluetooth A Smart Battery Sense, a BMV-712 Smart Battery Monitor or a SmartShunt can be used to communicate battery voltage and temperature (and current, in case of a BMV 712 or a SmartShunt) to one or more SmartSolar Charge Controllers. Synchronized parallel charging with Bluetooth Up to 10 units can be synchronized with Bluetooth. Fully discharged battery recovery function Will initiate charging even if the battery has been discharged to zero volts. Will reconnect to a fully discharged Li-ion battery with integrated disconnect function. VE.Direct For a wired data connection to a Color Control GX, other GX products, PC or other devices Remote on-off To connect for example to a VE.BUS BMS. Programmable relay Can be programmed to trip on an alarm, or other events. Optional: SmartSolar pluggable LCD display Simply remove the rubber seal that protects the plug on the front of the controller, and plug-in the display. Brand Victron Energy Manufacturer Part Number SCC115045310 GTIN 8719076042426 Battery Voltage 12 / 24 / 48V Auto Select (software tool needed to select 36V) Rated Charge Current 45A Nominal PV Power, 12V 650W Nominal PV Power, 24V 1300W Max. PV Short Circuit Current 30A Maximum PV Open Circuit Voltage 150V absolute maximum coldest conditions 145V start-up and operating maximum Efficiency 98% Charge Algorithm Multi-stage adaptive (eight preprorammed algorithms) or user defined algorithm Data Communication Port VE.Direct IP Rating IP43 (electronic components), IP22 (connection area) Dimensions H215 x W250 x D95mm Weight 3Kg Warranty 5 Years

Read more less

Part No: KG20-T204-GBA486 Switches - AC Isolators Kraus & Naimer AC Switch Suitable for three phase AC connection. Plastic Enclosures, Protection IP66, totally insulated, knock-outs Handle red, in the OFF-position lockable with padlocks, Plate Backing grey Dimensions (w x h x d): 100mm x 190mm X 93mm Switch interlocked with lid to prevent opening in ‘ON’ position Keywords: 17kW, KG20T204GBA486, Kraus & Naimer, Switches, AC Isolator Supplier Part No: KG20 T204/GBA486 KL51V Weight: 0.48 kg Rated Power: 17,320 W Poles: 4 Max Cable: 10 mm2 Max Voltage: 690 V Rated Current: 25 A Rated Voltage: 400 V Established in 1907 in Austria, Kraus & Naimer has grown to be one of world's highest quality and largest switch manufacturer in the world. For over 100 years Kraus & Naimer have been manufacturing top quality electrical switches and now offer the widest range of solar photovoltaic AC and DC isolators on the market. Every solar PV system requires at least one DC disconnector to isolate the PV array from the input to the inverter and at least one AC disconnector to isolate the inverter from the mains supply. Choosing a well proven and high quality product for these small but vital parts of any PV system is essential and there is no safer choice than Kraus & Naimer.

Read more less

It’s powerful enough to supply most common plug in appliances in your car, boat, caravan or home. A toroidal transformer provides a high peak power surge capacity, stable voltage, frequency and high quality sine-wave. Installation is simpler than ever before with terminals now more accessible for the installer, enabling a more professional finish. Bluetooth is built-in, and makes setting up your high power inverter easier than ever before.Configure alarms, alarm relay, voltage cut-off, output voltage, frequency, eco-mode and more, all from within VictronConnect.  Features of the Phoenix 12/1600 Smart Bluetooth built-in: fully configurable with a tablet or smartphone Low battery voltage alarm Low battery voltage cut-off and restart levels Dynamic cut-off: load dependent cut-off level Output voltage: 210 – 245V Frequency: 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level Alarm relay Monitoring: In- and output voltage, load and alarms  VE.Direct communication port The VE.Direct port can be connected to a computer (VE.Direct to USB interface cable needed) to configure and monitor the same parameters.  Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The Phoenix Smart Inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature.  High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools.  ECO mode When in ECO mode, the inverter will switch to standby when the load decreases below a preset value. Once in standby the inverter will switch on for a short period every 2,5 seconds (adjustable). If the load exceeds the preset level, the inverter will remain on.  Remote on/off A remote on/off switch or relay contact can be connected to a two pole connector. Alternatively, the H terminal (left) of the two pole connector can be switched to battery plus, or the L terminal (right) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example).  To transfer the load to another AC source: the automatic transfer switch For our low power inverters we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption. Alternatively use a MultiPlus with built-in transfer switch.  Control over system Want to have perfect control over your system from wherever you are whilst using your Phoenix Inverter 12/1600 Smart, why not have a look at the Cerbo GX. Simply connect through the Victron Remote Management (VRM) portal, or access directly, using the separate GX Touch, a MFD or the VictronConnect App thanks to its added Bluetooth capability. This latest addition to the GX-range combines all the best of connectivity, redefining smart power solutions in every way.   Brand Victron Energy Manufacturer Part Number PIN122161000 gtin 8719076057505 Voltage 12V Cont. Output Power at 25°C 1600VA Peak Power 3000W Output AC Voltage 230V Efficiency 92% Protection Category IP21 Dimensions H485 x W219 x D125mm Weight 12Kg Warranty 5 Years Bluetooth Enabled Yes Country of Manufacture China Peak Power 3000W

Read more less

Features of the Phoenix Inverter 24/375 VE.Direct VE.Direct communication port The VE.Direct port can be connected to: A computer (VE.Direct to USB interface cable needed) Apple and Android smartphones, tablets, MacBook’s and other devices (VE.Direct Bluetooth Smart dongle needed)  Fully configurable: Low battery voltage alarm trip and reset levels Low battery voltage cut-off and restart levels Dynamic cut-off: load dependent cut-off level Output voltage 210 – 245V Frequency 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level   Monitoring: In- and output voltage, % load and alarms   Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The Phoenix Inverter 24/375 VE.Direct are short circuit proof and protected against overheating, whether due to overload or high ambient temperature.  High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools.  ECO mode When in ECO mode, the Phoenix Inverter 24/375 VE.Direct will switch to standby when the load decreases below a preset value (min load: 15W). Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.  Remote on/off A remote on/off switch can be connected to a two pole connector, or between battery plus and the left hand contact of the two pole connector.   DC connection with screw terminals No special tools needed for installation.   Monitor, operate & control your system VictronConnect lets you get live status information and configure your Phoenix Inverter 24/375 VE.Direct when connected to a VE.Direct Bluetooth Smart Dongle.   The REC040010210R is the correct controller for the Phoenix Inverter VE.Directs.

Read more less

This unit has the UK plug. Features of the Phoenix Inverter 24/500 VE.Direct VE.Direct communication port The VE.Direct port can be connected to: A computer (VE.Direct to USB interface cable needed) Apple and Android smartphones, tablets, MacBook’s and other devices (VE.Direct Bluetooth Smart dongle needed) Fully configurable: Low battery voltage alarm trip and reset levels Low battery voltage cut-off and restart levels Dynamic cut-off: load dependent cut-off level Output voltage 210 – 245V Frequency 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level   Monitoring: In- and output voltage, % load and alarms   Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The Phoenix Inverter 24/500 VE.Direct are short circuit proof and protected against overheating, whether due to overload or high ambient temperature.  High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools.  ECO mode When in ECO mode, the Phoenix Inverter 24/500 VE.Direct will switch to standby when the load decreases below a preset value (min load: 15W). Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on. Remote on/off A remote on/off switch can be connected to a two pole connector, or between battery plus and the left hand contact of the two pole connector. DC connection with screw terminals No special tools needed for installation. Monitor, operate & control your system VictronConnect lets you get live status information and configure your Phoenix Inverter 24/500 VE.Direct when connected to a VE.Direct Bluetooth Smart Dongle.   The REC040010210R is the correct controller for the Phoenix Inverter VE.Directs.

Read more less

It’s powerful enough to supply most common plug in appliances in your car, boat, caravan or home. A toroidal transformer provides a high peak power surge capacity, stable voltage, frequency and high quality sine-wave. Installation is simpler than ever before with terminals now more accessible for the installer, enabling a more professional finish. Bluetooth is built-in, and makes setting up your high power inverter easier than ever before.Configure alarms, alarm relay, voltage cut-off, output voltage, frequency, eco-mode and more, all from within VictronConnect. Features of the Phoenix 24/1600 Smart Bluetooth built-in: fully configurable with a tablet or smartphone Low battery voltage alarm Low battery voltage cut-off and restart levels Dynamic cut-off: load dependent cut-off level Output voltage: 210 – 245V Frequency: 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level Alarm relay Monitoring: In- and output voltage, load and alarms  VE.Direct communication port The VE.Direct port can be connected to a computer (VE.Direct to USB interface cable needed) to configure and monitor the same parameters Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature. High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools. ECO mode When in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on. Remote on/off A remote on/off switch or relay contact can be connected to a two pole connector. Alternatively, the H terminal (left) of the two pole connector can be switched to battery plus, or the L terminal (right) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example). To transfer the load to another AC source: the automatic transfer switch For our low power inverters we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption. Alternatively use a MultiPlus with built-in transfer switch.   Control over system Want to have perfect control over your system from wherever you are whilst using your Phoenix Inverter 24/1600 Smart, why not have a look at the CerboGX. Simply connect through the Victron Remote Management (VRM) portal, or access directly, using the separate GX Touch, a MFD or the VictronConnect App thanks to its added Bluetooth capability. This latest addition to the GX-range combines all the best of connectivity, redefining smart power solutions in every way.   Brand Victron Energy Manufacturer Part Number PIN242161000 gtin 8719076057529 Voltage 24V Cont. Output Power at 25°C 1600VA Peak Power 3000W Output AC Voltage 230V Efficiency 94% Protection Category IP21 Dimensions H485 x W219 x D125mm Weight 12Kg Warranty 5 Years Bluetooth Enabled Yes Country of Manufacture China

Read more less

Features of the Phoenix Inverter 48/800 VE.Direct VE.Direct communication port The VE.Direct port can be connected to: A computer (VE.Direct to USB interface cable needed) Apple and Android smartphones, tablets, MacBook’s and other devices (VE.Direct Bluetooth Smart dongle needed) Fully configurable: Low battery voltage alarm trip and reset levels Low battery voltage cut-off and restart levels Dynamic cut-off: load dependent cut-off level Output voltage 210 – 245V Frequency 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level Monitoring: In- and output voltage, % load and alarms Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature. High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools. ECO mode When in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on. Remote on/off A remote on/off switch can be connected to a two pole connector, or between battery plus and the left hand contact of the two pole connector. DC connection with screw terminals No special tools needed for installation. Brand Victron Energy Manufacturer Part Number PIN481801400 gtin 8719076056898 Voltage 48V Cont. Output Power at 25ºC 800VA Peak Power 1500W Output AC Voltage 230V Efficiency 91% Protection Category IP21 Dimensions H105 x W216 x D305mm Weight 5.5Kg Warranty 5 Years Bluetooth Enabled No Plug Type UK Country of Manufacture China

Read more less

Features of the Phoenix 48/1600 Smart Bluetooth built-in: fully configurable with a tablet or smartphone Low battery voltage alarm Low battery voltage cut-off and restart levels Dynamic cut-off: load dependent cut-off level Output voltage: 210 – 245V Frequency: 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level Alarm relay Monitoring: In- and output voltage, load and alarms VE.Direct communication port The VE.Direct port can be connected to a computer (VE.Direct to USB interface cable needed) to configure and monitor the same parameters. Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature. High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools. ECO mode When in ECO mode, the inverter will switch to standby when the load decreases below a preset value. Once in standby the inverter will switch on for a short period every 2,5 seconds (adjustable). If the load exceeds the preset level, the inverter will remain on. Remote on/off A remote on/off switch or relay contact can be connected to a two pole connector. Alternatively, the H terminal (left) of the two pole connector can be switched to battery plus, or the L terminal (right) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example). To transfer the load to another AC source: the automatic transfer switch For our low power inverters we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption. Alternatively use a MultiPlus with built-in transfer switch. Brand Victron Energy Manufacturer Part Number PIN482161000 GTIN 8719076057543 Voltage 48V Cont. Output Power at 25°C 1600VA Peak Power 3000W Output AC Voltage 230V Efficiency 94% Protection Category IP21 Dimensions H485 x W219 x D125mm Weight 12Kg Warranty 5 Years Bluetooth Enabled Yes Country of Manufacture China

Read more less

Features Extra start-up power A unique feature of the SinusMax technology is very high start-up power. Conventional high frequency technology does not offer such extreme performance. Phoenix Inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances. Virtually unlimited power thanks to parallel and 3-phase operation capability Up to 6 units inverters can operate in parallel to achieve higher power output. Six 24/5000 units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.  To transfer the load to another AC source: the automatic transfer switch If an automatic transfer switch is required we recommend using the MultiPlus inverter/charger instead. The switch is included in these products and the charger function of the MultiPlus can be disabled. Computers and other electronic equipment will continue to operate without disruption because the MultiPlus features a very short switchover time (less than 20 milliseconds). Computer interface All models have a RS-485 port. All you need to connect to your PC is our MK3-USB VE.Bus to USB interface (see under accessories). Together with our VEConfigure software, which can be downloaded free of charge from our website, all parameters of the inverters can be customized. This includes output voltage and frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to VENet, the new power control network of Victron Energy, or to other computerized monitoring and control systems. Brand Victron Energy Manufacturer Part Number PIN243020000 Voltage 24 VA 3000 Peak Power (W) 6000 Max Efficiency 94% Programmable Relay Yes IP Rating IP21 Dimensions (Including Terminals) H362 x W258 x D218mm Weight (kg) 18 Warranty 5 Years

Read more less

The system has been designed for those who want to enjoy the comfort and freedom of a complete energy system without spending time on the installation of separate components and difficult technical procedures. Brand Victron Energy Manufacturer Part Number CEP121620000 Voltage 12 Transfer Switch (A) 16 Cont. Output Power at 25°C (VA) 1600 Peak Power (W) 3000 Max Efficiency 92% Zero Load Power (W) 8 Charge Current House Battery (A) 70 Charge Current Starter Battery (A) 4 Battery Temperature Sensor Yes Programmable Relay Yes Remote on-off Optional Protection Category IP21 Dimensions H510 x W214 x D110mm Weight (kg) 11.7 Warranty 5 Years Country of Manufacture China

Read more less

Features Two AC Outputs The main output has no break functionality. The MultiPlus takes over the supply to the connected loads in the event of a grid failure or when shore/generator power is disconnected. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on the input of the MultiPlus. Loads that should not discharge the battery, like a water heater for example can be connected to this output (second output available on models rated at 3 kVA and more). Virtually unlimited power thanks to parallel operation Up to 6 Multis can operate in parallel to achieve higher power output. Six 24/5000/120 units, for example, will provide 25 kW / 30 kVA output power with 720 Amps charging capacity. Three phase capability In addition to parallel connection, three units of the same model can be configured for three phase output. But that’s not all: up to 6 sets of three units can be parallel connected for a huge 75 kW / 90 kVA inverter and more than 2000 Amps charging capacity. PowerControl – Dealing with limited generator, shore side or grid power The MultiPlus is a very powerful battery charger. It will therefore draw a lot of current from the generator or shore side supply (nearly 10 A per 5 kVA Multi at 230 VAC). With the Multi Control Panel a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded. PowerAssist – Boosting the capacity of shore or generator power This feature takes the principle of PowerControl to a further dimension. It allows the MultiPlus to supplement the capacity of the alternative source. Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery. Solar energy: AC power available even during a grid failure The MultiPlus can be used in off grid as well as grid connected PV and other alternative energy systems. Loss of mains detection software is available. System configuring In case of a stand-alone application, if settings have to be changed, this can be done in a matter of minutes with a DIP switch setting procedure. Parallel and three phase applications can be configured with VE.Bus Quick Configure and VE.Bus System Configurator software.   Brand Victron Energy Manufacturer Part Number CMP122200000 Voltage 12 Transfer Switch (A) 30 Cont. Output Power at 25°C (VA) 2000 Peak Power (W) 3500 Max Efficiency 93% Zero Load Power (W) 9 Charge Current House Battery (A) 80 Charge Current Starter Battery (A) 4 Battery Temperature Sensor Yes Programmable Relay Yes Remote on-off Yes Protection Category IP21 Dimensions H520 x W255 x D125mm Weight (kg) 12 Warranty 5 Years Country of Manufacture India

Read more less

Features Bluetooth built-in: fully configurable with a tablet or smartphone Low battery voltage alarm Low battery voltage cut-off and restart levels Dynamic cut-off: load dependent cut-off level Output voltage: 210 – 245V Frequency: 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level Alarm relay Monitoring: In- and output voltage, load and alarms VE.Direct communication port The VE.Direct port can be connected to a computer (VE.Direct to USB interface cable needed) to configure and monitor the same parameters. Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature. High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools. ECO mode When in ECO mode, the inverter will switch to standby when the load decreases below a preset value. Once in standby the inverter will switch on for a short period every 2,5 seconds (adjustable). If the load exceeds the preset level, the inverter will remain on. Remote on/off A remote on/off switch or relay contact can be connected to a two pole connector. Alternatively, the H terminal (left) of the two pole connector can be switched to battery plus, or the L terminal (right) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example). To transfer the load to another AC source: the automatic transfer switch For our low power inverters we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption. Alternatively use a MultiPlus with built-in transfer switch. Brand Victron Energy Manufacturer Part Number PIN482500000 GTIN 8719076047940 Voltage 48V Cont. output power at 25ºC 5000VA Peak power 10000W Parallel and 3-phase operation No Programmable Relay Yes Max. efficiency 96% Battery-Connection M8 Bolts VE.Direct Communication Port For remote monitoring and system integration Dimensions H555 x W295 x D160mm Weight 28Kg Warranty 5 Years

Read more less

Features All-in-one solar power solution The EasySolar combines a MPPT solar charge controller, an inverter/charger and AC distribution in one enclosure. The product is easy to install, with a minimum of wiring.   The solar charge controller: Blue Solar MPPT 100/50 Up to three strings of PV panels can be connected to three sets of MC4 (PV-ST01) PV connectors.   The inverter/charger: MultiPlus Compact 12/1600/70 or 24/1600/40 The MPPT charge controller and the MultiPlus Compact inverter/charger share the DC battery cables (included). The batteries can be charged with solar power (BlueSolar MPPT) and/or with AC power (inverter/charger) from the utility grid or a genset.   AC distribution The AC distribution consists of a RCD (30 mA/16 A) and four AC outputs protected by two 10A and two 16A circuit breakers. One 16A output is controlled by the AC input: it will switch on only when AC is available.   PowerAssist Unique PowerAssist technology protects the utility or generator supply from being overloaded by adding extra inverter power when needed.   Unique solar application software Several software programs (Assistants) are available to configure the system for various grid interactive or stand-alone applications.   Brand Victron Energy Manufacturer Part Number CEP121620000 GTIN 8719076021599 Voltage 12V Transfer Switch 16A Continuous Output Power at 25°C 1600VA/1300W Peak power 3000W Charger Current House Battery 70A Battery Temperature Sensor Yes Programmable Relay Yes Ingress Protection IP22 Battery-Connection Battery cables of 1.5 meter Dimensions (Including Terminals) H745 x W214 x D110mm Weight 15Kg Warranty 5 Years Country of Manufacture China

Read more less

It covers all DC terminals, preventing accidental or inquisitive contact with terminal screws. Brand Victron Energy Manufacturer Part Number SCC950300210 Warranty 5 Years

Read more less

Brand Victron Energy Manufacturer Part Number SCA000100100 Warranty 5 Years

Read more less

Brand Victron Energy Manufacturer Part Number SCA500100000 Warranty 5 Years

Read more less

Brand Victron Energy Manufacturer Part Number SCA500200000 Warranty 5 Years

Read more less

Brand Victron Energy Manufacturer Part Number CIP132125010 GTIN 8719076054658 Appr. Voltage Drop 60mV Cold Resistance 0.3 Warranty 5 Years

Read more less

Features Perfect chargers for any type of battery Charge voltage can be precisely adjusted to suit any sealed or unsealed battery system. In particular, sealed maintenance free batteries must be charged correctly in order to ensure a long service life. Overvoltage will result in excessive gassing and venting of a sealed battery. The battery will dry out and fail. Suitable for AC and DC supply (AC-DC and DC-DC operation) Except for the 3-phase input models, the chargers also accept a DC supply. Controlled charging Every TG Charger has a microprocessor, which accurately controls the charging in three steps. The charging process takes place in accordance with the IUoUo characteristic and charges more rapidly than other processes. Use of TG Chargers as a power supply As a result of the perfectly stabilized output voltage, a TG Charger can be used as a power supply if batteries or large buffer capacitors are not available. Two outputs to charge 2 battery banks (24V models only) The TG Chargers feature 2 isolated outputs. The second output, limited to approximately 4A and with a slightly lower output voltage, is intended to top up a starter battery. To increase battery life: temperature compensation Every Skylla TG Charger comes with a battery temperature sensor. When connected, charge voltage will automatically decrease with increasing battery temperature. This feature is especially recommended for sealed batteries which otherwise might be overcharged and dry out due to venting. Battery voltage sense In order to compensate for voltage loss due to cable resistance, TG Chargers are provided with a voltage sense facility so that the battery always receives the correct charge voltage. Brand Victron Energy Manufacturer Part Number SDTG2400301 Voltage 24 Charger Current House Battery 30A Charger Current Starter Battery 4A Recommended Battery Capacity 150 – 500Ah Battery Connection M8 Studs Outputs 1+1 Temperature Sensor Yes Can Be Used As Power Supply Yes IP Rating IP21 Dimensions H365 x W250 x D147mm Weight (kg) 5.5 Warranty 5 Years

Read more less

Brand Victron Energy Manufacturer Part Number SCC010010050 GTIN 8719076046189 Battery Voltage 12/24 V automatic system voltage detection Rated Charge Current 10A Maximum Solar Voltage 28V / 55V Load Output Manual control + low voltage disconnect + timer Grounding Common positive IP Rating IP20 Dimensions H96 x W169 x D36mm Weight 0.15Kg Warranty 5 Years

Read more less

Features Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30 % compared to PWM charge controllers and by up to 10 % compared to slower MPPT controllers. Advanced Maximum Power Point Detection in case of partial shading conditions If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP. Outstanding conversion efficiency No cooling fan. Maximum efficiency exceeds 98 %. Flexible charge algorithm Fully programmable charge algorithm, and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details). Extensive electronic protection Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection. Internal temperature sensor and optional external battery voltage, temperature and current sensing via Bluetooth A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature (and current, in case of a BMV-712 or a SmartShunt) to one or more BlueSolar Charge Controllers. (VE.Direct Bluetooth Smart dongle needed) Real-time data display options Color Control GX or other GX devices: see the Venus documents on our website. A smartphone or other Bluetooth-enabled device: VE.Direct Bluetooth Smart dongle needed. Brand Victron Energy Manufacturer Part Number SCC010070300 GTIN 8719076025528 Battery Voltage 12/24/48V Auto Select (software tool needed to select 36V) Rated Charge Current 70A Nominal PV Power, 12V 1000W Nominal PV Power, 24V 2000W Max. PV Short Circuit Current 50A Maximum PV Open Circuit Voltage 150V absolute maximum coldest conditions 145V start-up and operating maximum Efficiency 98% Charge Algorithm Multi-stage adaptive Data Communication Port VE.Direct IP Rating IP43 (electronic components), IP22 (connection area) Dimensions H215 x W250 x D95mm Weight 3Kg Warranty 5 Years

Read more less

Features Two AC Outputs The main output has no break functionality. The MultiPlus takes over the supply to the connected loads in the event of a grid failure or when shore/generator power is disconnected. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on the input of the MultiPlus. Loads that should not discharge the battery, like a water heater for example can be connected to this output (second output available on models rated at 3 kVA and more). Virtually unlimited power thanks to parallel operation Up to 6 Multis can operate in parallel to achieve higher power output. Six 24/5000/120 units, for example, will provide 25 kW / 30 kVA output power with 720 Amps charging capacity. Three phase capability In addition to parallel connection, three units of the same model can be configured for three phase output. But that’s not all: up to 6 sets of three units can be parallel connected for a huge 75 kW / 90 kVA inverter and more than 2000 Amps charging capacity. PowerControl – Dealing with limited generator, shore side or grid power The MultiPlus is a very powerful battery charger. It will therefore draw a lot of current from the generator or shore side supply (nearly 10 A per 5 kVA Multi at 230 VAC). With the Multi Control Panel a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded. PowerAssist – Boosting the capacity of shore or generator power This feature takes the principle of PowerControl to a further dimension. It allows the MultiPlus to supplement the capacity of the alternative source. Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery. Solar energy: AC power available even during a grid failure The MultiPlus can be used in off grid as well as grid connected PV and other alternative energy systems. Loss of mains detection software is available. System configuring In case of a stand-alone application, if settings have to be changed, this can be done in a matter of minutes with a DIP switch setting procedure. Parallel and three phase applications can be configured with VE.Bus Quick Configure and VE.Bus System Configurator software. Brand Victron Energy Manufacturer Part Number PMP485021010 Voltage 48 Transfer Switch (A) 100 Cont. Output Power at 25°C (VA) 5000 Peak Power (W) 10000 Max Efficiency 95% Zero Load Power (W) 35 Charge Current House Battery (A) 70 Charge Current Starter Battery (A) 4 (12 V and 24 V models only) Battery Temperature Sensor Yes Programmable Relay Yes Remote on-off Yes Protection Category IP21 Dimensions H444 x W328 x D240mm Weight (kg) 30 Warranty 5 Years Country of Manufacture India

Read more less

Features Bluetooth inside With Bluetooth built-in, the BMV Smart is ready for the Internet of Things (IoT) era. With Bluetooth being implemented in most other Victron Energy products, wireless communication between products will simplify system installation and enhance performance. Download the Victron Bluetooth app Use a smartphone or other Bluetooth enabled device to – customize settings, – monitor all important data on single screen, – view historical data, and to – update the software when new features become available. Easy to install All electrical connections are to the quick connect PCB on the current shunt. The shunt connects to the monitor with a standard RJ12 telephone cable. Included: RJ 12 cable (10 m) and battery cable with fuse (2 m); no other components needed. Also included are a separate front bezel for a square or round display appearance, a securing ring for rear mounting and screws for front mounting. Midpoint voltage monitoring One bad cell or one bad battery can destroy a large, expensive battery bank. When batteries are connected in series, a timely warning can be generated by measuring the midpoint voltage. Please see the BMV manual, section 5.2, for more information. We recommend the Battery Balancer (BMS012201000) to maximize service life of series-connected lead-acid batteries. Very low current draw from the battery Current consumption: 0,7Ah per month (1mA) @12V and 0,6Ah per month (0,8mA) @ 24V Especially Li-ion batteries have virtually no capacity left when discharged until low voltage shutdown. After shutdown due to low cell voltage, the capacity reserve of a Li-ion battery is approximately 1Ah per 100Ah battery capacity. The battery will be damaged if the remaining capacity reserve is drawn from the battery. A residual current of 10mA for example may damage a 200Ah battery if the system is left in discharged state during more than 8 days. Bi-stable alarm relay Prevents increased current draw in case of an alarm. Brand Victron Energy Manufacturer Part Number BAM030712000R Supply Voltage Range 6.5-70 VDC Battery Capacity (Ah) 1-9999 Temperature Sensor Optional VE.Direct Communication Port Yes Protection Category IP55 Front Bezel 69 x 69mm Body Diameter & Depth 52 x 31mm Warranty 5 Years Country of Manufacture Malaysia

Read more less

Features Unique PowerAssist feature The Quattro will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery. Virtually unlimited power thanks to parallel operation Up to 6 Quattros can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check our datasheets to see which models have paralleling, three phase and split phase capabilities. Remote Monitoring and Control Monitor and control your Quattro and system or systems’ locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for hire vehicles and more… Split phase and three phase capability Two units can be configured for split phase, and three units can be configured for three phase output. But that’s not all: up to 6 sets of three units can be parallel connected to provide 144kW / 180kVA inverter power and more than 2500A charging capacity. For more detail please enter parallel in the search box on our website. Solar energy: AC power available even during a grid failure The Quattro can be used in off grid as well as grid connected PV and other alternative energy systems. Loss of mains detection software is available. System configuring In case of a stand-alone application, if settings have to be changed, this can be done in a matter of minutes with a DIP switch setting procedure. Parallel and three phase applications can be configured with VE.Bus Quick Configure and VE.Bus System Configurator software. Off grid, grid interactive and self-consumption applications, involving grid-tie inverters and/or MPPT Solar Chargers can be configured with Assistants (dedicated software for specific applications).   Brand Victron Energy Manufacturer Part Number QUA125020000 Voltage 12 Transfer Switch (A) Yes Cont. Output Power at 25°C (VA) 5000 Peak Power (W) 10000 Max Efficiency 94% Zero Load Power (W) 30 Charge Current House Battery (A) 220 Charge Current Starter Battery (A) 4 (12V and 24V models only) Battery Temperature Sensor Yes Programmable Relay 3x Remote on-off Yes Protection Category IP21 Dimensions H470 x W350 x D280mm Weight (kg) 34 Warranty 5 Years Country of Manufacture India

Read more less

  The load output of an MPPT 75/15 or MPPT 100/15, for example, can be used to control an inverter. Some inverters will switch on when the remote control input is pulled high. The remote control input of other inverters must be pulled down to switch on. Pull down to switch on is needed for the Victron inverters model Phoenix 12/180, 24/180, 12/350 and 24/350. These inverters should be interfaced to the load output of the MPPT 75/15 or MPPT 100/15 with the inverting remote on-off cable. All Phoenix Inverters rated at 3kVA and more and all Multi C’s, Multi’s and Quattro’s also require active pull down to switch on, and the inverting remote on-off cable can be used to interface between the remote on-off terminal and a source signal that turns high when switch on is required. Brand Victron Energy Manufacturer Part Number ASS030550120 Warranty 5 Years

Read more less

Features of the Quattro 48/8000-110-100 Two AC Inputs & two AC Outputs The Quattro can be connected to two independent AC sources, for example shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.   Unique PowerAssist feature The Quattro will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.   Virtually unlimited power thanks to parallel operation Up to 6 Quattros can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check our datasheets to see which models have paralleling, three phase and split phase capabilities.   Remote Monitoring and Control When coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Quattro and system or systems’ locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, from adjusting your Quattro to auto starting a backupgenerator and more…   Want to have perfect control over your system from wherever you are whilst using your Quattro 48/8000, why not have a look at the Cerbo GX. Simply connect through the Victron Remote Management (VRM) portal, or access directly, using the separate GX Touch, a MFD or the VictronConnect App thanks to its added Bluetooth capability. This latest addition to the GX-range combines all the best of connectivity, redefining smart power solutions in every way.   Watch the new video that explains all there is to know about installing the new Cerbo GX & GX Touch 50   The MK3-USB allows the Quattro to connect to a computer for configuration and firmware updates.

Read more less

Lighting Applications The cable is designed for lighting applications in solar energy systems.Energy consumption can be significantly reduced by the ability to dim lighting when needed. Lower power consumption will reduce the overall system cost. Also, the availability of the lighting will increase, even in case of a partially charged battery in low sun.The cable connects the TX output of the VE.Direct connector of a MPPT charger with the PWM dimmer input of the LED driver. Virtual load output The cable is designed for adding load output functionality to the larger MPPT chargers (MPPT 100/30 and larger) that do not have a load output. The cable connects the TX output of the VE.Direct connector of a MPPT charger with a battery protect or a solid state relay to switch a load on or off. Brand Victron Energy Manufacturer Part Number ASS030550500 Warranty 5 Years

Read more less

MPPT: Ultra Fast Maximum Power Point Tracking By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing. Remote Monitoring and Control Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations – even when there is no internet connection or phone signal nearby – you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally. Load output The intelligent Load output function prevents damage caused by running batteries ‘flat’. You can configure the voltage at which SmartSolar disconnects a load – thereby preventing excessive drain on your batteries. And here’s the clever bit: SmartSolar will attempt a 100% recharge every day. If it can’t – during periods of poor weather – it raises the disconnect voltage, daily, until it achieves success. We call this feature BatteryLife because it maintains the health, and extends the life of your battery. Bluetooth Smart built-in The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers. VE.Direct For a wired data connection to a Color Control GX, other GX products, PC or other devices Battery Life: intelligent battery management When a solar charge controller is not able to recharge the battery to its full capacity within one day, the result is often that the battery will continually be cycled between a ‘partially charged’ state and the ‘end of discharge’ state. This mode of operation (no regular full recharge) will destroy a lead-acid battery within weeks or months. The Battery Life algorithm will monitor the state of charge of the battery and, if needed, day by day slightly increase the load disconnect level (i.e. disconnect the load earlier) until the harvested solar energy is sufficient to recharge the battery to nearly the full 100%. From that point onwards, the load disconnect level will be modulated so that a nearly 100% recharge is achieved about once every week. Internal temperature sensor Compensates absorption and float charge voltage for temperature. Optional external battery voltage and temperature sensing via Bluetooth A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers. Brand Victron Energy Manufacturer Part Number SCC110015060R GTIN 8719076040811 Battery Voltage 12/24 Auto Select Rated Charge Current 15A Nominal PV Power, 12V 220W Nominal PV Power, 24V 440W Max. PV Short Circuit Current 15A Maximum PV Open Circuit Voltage 100V Efficiency 98% Charge Algorithm Multi-stage adaptive Data Communication Port VE.Direct IP Rating IP43 (electronic components), IP22 (connection area) Dimensions H100 x W113 x D50mm Weight 0.6Kg Warranty 5 Years

Read more less

Part No: KG20-T104GB Switches - DC Isolators Kraus & Naimer DC Switch Switch - Disconnectors, 4 pole - for 2 strings             IP66/67 Protection             Black/Grey Padlockable Handle – lockable in the OFF-position             Class II compliant, Grey Insulated Enclosure             Switch Interlocked with lid to prevent opening in “ON” position             Rated for use in ambient temperatures of 50°C UK Please note: We will have reduced availbility of K&N switch gear for the immediate future. We have sourced alternative options for this period of low stock, please contact your account manager for more information. Supplier Part No: KG20 T104/GB-P103 KL51V Weight: 0.43 kg Poles: 4 Max Cable: 6 mm2 Max Voltage: 460 V Rated Current: 25 A Rated Voltage: 220 V Rated Current: 21 A Rated Voltage: 280 V Rated Current: 20 A Rated Voltage: 340 V Rated Current: 18 A Rated Voltage: 400 V Rated Current: 11 A Rated Voltage: 460 V Established in 1907 in Austria, Kraus & Naimer has grown to be one of world's highest quality and largest switch manufacturer in the world. For over 100 years Kraus & Naimer have been manufacturing top quality electrical switches and now offer the widest range of solar photovoltaic AC and DC isolators on the market. Every solar PV system requires at least one DC disconnector to isolate the PV array from the input to the inverter and at least one AC disconnector to isolate the inverter from the mains supply. Choosing a well proven and high quality product for these small but vital parts of any PV system is essential and there is no safer choice than Kraus & Naimer.

Read more less
